382-079671 KONGSBERG Industrial/Marine Automation PCB Module

• Brand
  KONGSBERG
• Model
  382-079671
• Product Name
  Industrial PCB Module
• Weight
  0.45 kg (450 g)
• Dimensions
  160 mm (L) x 100 mm (W) x 25 mm (H)
• Original
  Norway
• Customs HS
  85340090
• Operating temperature
  -25°C to +70°C
• Storage temperature
  -40°C to +85°C
• Warranty
  12 month
• Humidity
  5% – 95% RH
• Product Status
  new and original

Input Specifications

Supply Voltage: 24 V DC (nominal), tolerance -15% to +20% (20.4 V DC – 28.8 V DC)

Input Current (Typical): 180 mA at 24 V DC

Input Channels: 8 x configurable digital/analog input channels

Digital Input Signal: 24 V DC, potential-free or Namur compliant

Analog Input Range: 4–20 mA / 0–10 V DC (software configurable)

Input Isolation: Galvanic isolation (500 V) between inputs and system logic

Output Specifications

Output Channels: 6 x configurable digital/relay output channels

Digital Output Type: High-side driver (HSD), short-circuit proof, 1 A per channel

Relay Output: 3 A @ 250 V AC, 5 A @ 30 V DC (resistive load)

Analog Output Range: 4–20 mA / 0–10 V DC (software configurable)

Output Isolation: Galvanic isolation between outputs and system logic

Electrical & Mechanical Characteristics

Power Consumption: Max. 4.3 W (typical 3.2 W)

Protection Class: IP20 (for enclosed cabinet mounting)

Connection: Screw terminals (2.5 mm²) / PCB edge connectors

Vibration Resistance: 5g (IEC 60068-2-6)

Shock Resistance: 25g (IEC 60068-2-27)

Material: FR-4 glass-reinforced epoxy laminate PCB

Mounting: DIN rail or direct panel mounting

Certifications: DNV, GL, ABS, LR, CCS, CE, ATEX (Zone 2 hazardous area compatible)

Functional Features

Microcontroller: 32-bit industrial-grade processor for real-time signal processing

Memory: 512 KB Flash, 128 KB SRAM for configuration and data storage

Communication Interface: Dual redundant RS-485 (SPBus) / CAN bus ports

Communication Protocols: Modbus RTU, KONGSBERG SPBus protocol

Built-In Self Test (BIST): Continuous diagnostic monitoring of all I/O channels

Channel Configuration: Software configurable I/O (each channel assignable as DI/DO/AI/AO)

Fault Detection: Over-voltage, over-current, short-circuit, and line fault monitoring

Status Indicators: LED indicators for power, communication, input/output status, and faults

Redundancy: Support for dual bus communication and redundant power input

Applications

Marine automation and control systems

Ship engine control and monitoring

Dynamic positioning systems (DPS)

Offshore platform control and instrumentation

Industrial process control and data acquisition

Remote I/O systems for hazardous environments

Tank gauging and cargo monitoring systems

Power generation and distribution control

Navigation and safety systems on commercial vessels
