EATON XV-102-B6-35TQR-1AL DCS touch screen in stock

• Brand
  EATON
• Model
  XV-102-B6-35TQR-1AL
• Product Name
  3.5 Inch Integrated HMI-PLC Touch Panel Display
• Weight
  0.65 kilograms
• Dimensions
  136mm * 108mm * 42mm (W* H* D)
• Original
  Czech Republic
• Customs HS
  85371000
• Operating temperature
  -20°C to +60°C
• Storage temperature
  -30°C to +70°C
• Warranty
  12 month

EATON XV-102-B6-35TQR-1AL Complete Product Introduction and Technical Specifications

Input Technical Parameters:
The rated power supply input is 24 VDC with wide voltage tolerance of -20% to +25%, supporting stable power supply under industrial voltage fluctuation conditions. The typical power consumption is low, with maximum working power below 10W. It is equipped with universal signal input terminals and integrated communication input ports including RS-485, CAN and Ethernet, supporting data collection and signal receiving from on-site sensors, buttons and various automation equipment.

Output Technical Parameters:
This HMI-PLC integrated module supports Ethernet and serial communication data output for real-time data upload and remote monitoring transmission. It provides on-site visual touch display output and control logic output linkage, realizing on-site parameter modification, equipment operation control and remote data interaction. It also comes with system status and fault indication output for quick equipment operation judgment and abnormal prompt.

Key Product Advantages:
The integrated HMI and PLC dual-function design saves cabinet installation space and reduces on-site wiring and procurement costs compared with separate configuration solutions. Fanless passive cooling structure reduces failure points and later maintenance work, adapting to long-term uninterrupted industrial operation. Resistive touch panel supports stable operation in dusty, humid and vibration industrial environments, not easy to be affected by on-site harsh conditions. It supports Modbus TCP, EtherNet/IP and other common industrial protocols with good equipment compatibility and easy system integration. Compact and lightweight design simplifies on-site installation and debugging work, and the wide temperature working range ensures reliable operation in different industrial scenarios.

Detailed Application Cases:
In factory automated production lines, it is used for small production unit on-site operation monitoring, parameter adjustment and equipment linkage control, realizing independent control and on-site management of single production workstation. In water treatment and pumping station projects, it applies to water pump operation control, water pressure and liquid level real-time monitoring and automatic interlock protection, ensuring stable and safe operation of water treatment system. In packaging machinery and small processing equipment manufacturing industry, it serves as the core control and operation display terminal of mechanical equipment, completing equipment automatic operation control and on-site manual operation management. In building intelligent ventilation and HVAC control systems, it is used for fan and air conditioning equipment operation monitoring, temperature and humidity parameter adjustment and automatic energy-saving control.

Core Product Functions:
It integrates real-time on-site operation and monitoring display function, allowing operators to view production data, equipment running status and process parameters directly on the touch screen, and manually modify set values and control parameters. The built-in PLC logic control function can independently complete on-site automatic logic interlock, sequence control and equipment start-stop control without additional external PLC controller. It supports multi-point data collection, real-time data recording and simple fault alarm prompt, and realizes remote data transmission and system networking monitoring through Ethernet and serial communication interfaces. It also has system self-diagnosis function to automatically detect communication exceptions and equipment operating faults.

•
