Description
-
BrandEaton
-
ModelXV-102-D0-57TVR-10
-
Product NameIndustrial Touch Panel
-
Weight0.52 kilograms
-
Dimensions170mm*130mm*39mm (W*H*D)
-
OriginalCzech Republic
-
Customs HS85371000
-
Operating temperature-20°C to +60°C
-
Storage temperature-30°C to +70°C
-
Warranty12 MONTH
Eaton XV-102-D0-57TVR-10 Complete Product Introduction and Technical Specifications
Input Technical Parameters:
The rated power supply input is 24 VDC with a wide voltage tolerance range of -25% to +30%, adapting to unstable industrial on-site power supply fluctuations. The maximum power consumption is 10W with low energy consumption design. It is equipped with multiple communication input interfaces including Ethernet, RS232 and RS485, and supports digital signal collection from on-site sensors, buttons and other automation equipment, compatible with all mainstream industrial PLC and control systems.
Output Technical Parameters:
Adopts 5.7-inch high-definition TFT color resistive touch display output for clear on-site data visualization and operation interaction. It supports multi-protocol data communication output such as Modbus TCP and EtherNet/IP for remote data transmission and upper system monitoring linkage. It integrates system status and fault indication output functions to feedback real-time device running status and abnormal alarm information for on-site maintenance and remote management.
Key Product Advantages:
Integrated HMI and PLC dual-function design effectively reduces equipment procurement cost and cabinet installation space, simplifying overall system construction and on-site wiring work. Fanless passive cooling structure has no vulnerable rotating parts, lowering failure rate and reducing later daily maintenance workload. Industrial resistive touch screen can work stably in dusty, humid and vibrating harsh industrial environments with long service life. It supports multiple mainstream industrial communication protocols with excellent compatibility and convenient system integration and program debugging. Compact integrated structure is easy for on-site installation and fixed debugging, and wide temperature working design ensures reliable operation in various industrial working conditions.
Detailed Application Cases:
In automated assembly and processing machinery industry, it is used as the core control and operation terminal for single machine and small production line equipment, realizing on-site parameter setting, equipment operation control and production status real-time monitoring to improve production efficiency. In water supply and sewage treatment projects, it applies to water pump group automatic control, liquid level and pressure monitoring and equipment fault alarm interlock, ensuring stable and safe operation of water treatment system. In packaging, printing and textile machinery manufacturing, it completes mechanical equipment automatic operation control, production data statistics and on-site manual operation management, realizing stable and orderly mechanical production. In factory HVAC and building intelligent ventilation control systems, it is used for fan and air conditioning equipment operation monitoring, temperature and humidity parameter adjustment and automatic energy-saving control to achieve stable and efficient building automatic management.
Core Product Functions:
It provides real-time on-site production data display, equipment running status monitoring and process parameter modification through intuitive touch operation. The built-in PLC logic control function can independently complete equipment automatic start-stop, sequence control and safety interlock protection without additional external PLC controller. It supports multi-point on-site data acquisition, real-time data recording and equipment fault alarm prompt, and realizes remote networking monitoring and data uploading through Ethernet and serial communication ports. It also has built-in system self-diagnosis function to automatically detect communication faults and equipment operation abnormalities for timely maintenance reminders.
