SCL055/30010/A/00/AA/AA/01/001 ELAU DCS servo motor

• Brand
  ELAU
• Model
  SCL055/30010/A/00/AA/AA/01/001
• Product Name
  Integrated Servo Motor Drive Unit
• Country of Origin
  Germany
• HS Code
  85015200
• Dimensions
  125mm*150mm*50mm
• Weight
  2.5kg
• Operating Temperature
  0°C to +55°C
• Storage Temperature
  -25°C to +80C
• Power Supply
  3000 rpm
• Warranty
  12 month
• Product Status
  New and original

ELAU SCL055/30010/A/00/AA/AA/01/001 Product Introduction and Technical Parameters
Electrical Input and Output Parameters

Power Supply Input: Supports single-phase or three-phase AC power supply, with built-in power network filter and discharge bleeder circuit to suppress power grid interference and ensure stable power input. The device is compatible with industrial standard power supply environments for automated production equipment.

Power Output Performance: Equipped with 5 kW rated power output and 10 kW peak power output, providing strong overload operation capability. It supports DC bus power supply for up to 32 SCL-055 units in parallel, realizing centralized power supply and unified power management for multi-axis motion systems.

Torque and Speed Output: It delivers a continuous holding torque of 1.0 Nm (RMS) and a peak torque of 4.4 Nm, with a rated operating speed of 3000 rpm. The high-torque and high-speed output characteristics meet the requirements of fast acceleration, frequent start-stop and precise positioning in high-speed automated machinery.

Encoder Feedback: Built-in high-resolution encoder with 1 million increments per revolution, supporting automatic motor parameter calibration and high-precision position feedback to achieve micron-level positioning accuracy.

Working Temperature Conditions

The servo unit supports a standard industrial operating temperature range of 0°C to +55°C, adapting to conventional factory production environment temperatures. With optimized heat dissipation structure and low heat generation circuit design, it can maintain stable continuous operation under high-speed and high-load working conditions. The device also features excellent temperature resistance stability, avoiding performance attenuation or position deviation caused by long-term temperature rise, and supports long-cycle uninterrupted industrial operation.

Core Product Features

This integrated servo unit adopts an integrated motor-drive fusion structure, realizing one-piece integration of power drive, motion control and signal feedback. It supports single-cable wiring design, which greatly simplifies on-site wiring work and reduces wiring failure risks. The product is equipped with an IP67 high-level protection grade, with professional anti-corrosion surface treatment and waterproof and dustproof structure, effectively preventing liquid penetration, dust erosion and chemical corrosion, making it suitable for hygienic and wet industrial scenarios such as food and beverage packaging. It adopts reinforced bearing structure, which can withstand high radial loads and support direct connection with belt drive mechanisms. In addition, it is equipped with comprehensive built-in diagnosis functions, realizing real-time monitoring of operating status, fault self-inspection and abnormal alarm, facilitating equipment maintenance and fault troubleshooting.

Core Functions

It realizes full closed-loop high-precision rotational motion control and dynamic positioning control, supporting high-speed start-stop, constant-speed operation and precise positioning of automated machinery. It supports multi-device synchronous linkage control, enabling coordinated operation of multiple servo units on the same production line. The built-in power filter and bleeder circuit realize power grid signal purification and safe voltage discharge, improving equipment operation safety and anti-interference ability. The automatic parameter identification and calibration function can adapt to different mechanical load characteristics without manual complicated parameter setting. It also supports real-time operating data collection and fault diagnosis, providing data support for equipment intelligent management and predictive maintenance.

Product Advantages

First, ultra-high power density design achieves smaller volume and lighter weight while maintaining high power output, saving equipment installation space and optimizing mechanical structure layout. Second, the integrated all-in-one structure eliminates the need for separate drive cabinets and connecting cables, reducing equipment procurement and installation costs, and lowering later maintenance workload. Third, the single-cable installation design simplifies on-site construction, shortens equipment commissioning cycle and improves production line deployment efficiency. Fourth, IP67 protection and anti-corrosion treatment endow the product with excellent environmental adaptability, adapting to harsh working conditions such as humidity, dust and chemical cleaning. Fifth, low inertia mechanical structure and high overload tolerance ensure excellent dynamic acceleration performance, reduce equipment energy consumption and stray heat, and improve overall production efficiency. Sixth, strong expandable control performance supports centralized control of up to 99 units by a single controller, suitable for large-scale multi-axis automated production lines.

Application Cases and Scenarios

This product is widely applied in high-precision and high-speed automated packaging and processing equipment, and is the core motion control component of ELAU PacDrive automatic systems. It is extensively used in food, beverage, pharmaceutical and daily chemical filling production lines, including high-speed capping machines, automatic labeling machines, rotary table filling equipment and other core equipment. It is perfectly suitable for Gen3 intelligent filling and packaging machinery, and can be embedded in rotating workbenches and compact automated mechanical structures to complete high-precision capping, labeling and filling positioning operations. In addition, it is also applied in automated sorting, conveying and precision positioning equipment in light industrial automation fields, providing stable and efficient motion control support for high-speed, high-precision and hygienic industrial production scenarios.
