OVATION 5X00228G01 PC Board

• Brand
  OVATION
• Model
  5X00228G01
• Product Name
  PC Board Assembly Direct, QPTO to QTO Q-Line Migration Q-Card
• Country of Origin
  United States
• HS Code
  8538900000
• Dimensions
  12.5 cm High x 19.5 cm Deep x 2.2 cm Wide
• Weight
  0.35 kg to 0.45 kg
• Operating Temperature
  0°C to +60°C (32°F to +140°F)
• Storage Temperature
  -40°C to +85°C (-40°F to +185°F)
• Power Supply
  24VDC
• Warranty
  12 month
• Product Status
  New and original

OVATION 5X00228G01 Input & Output Parameters

Operational Power Supply Input: Draws regulated internal operating voltage (typically +5V DC and +12V DC logic rails) directly from the backplane connector when slotted into the migration chassis.

Signal Mapping Type: High-density bi-directional data routing, mirroring hardware signals between older QPTO/QTO termination blocks and modern Ovation controller backplane paths.

Interface Protocol Support: Embedded block transfer routines and extended register protocols to maintain signal integrity during data exchanges across differing architectural generations.

Channel Capacity: Layout configuration supports direct matching with standard 16-channel or 32-channel legacy discrete and analog Q-Line card form factors.

OVATION 5X00228G01 Wiring & Installation Methods

Chassis Slide-In Mounting: Insert the 5X00228G01 migration card into its designated slot within the specialized Q-Line Migration/Transition chassis. Ensure that the card alignment rails are correctly tracked before firmly pushing the assembly into the backplane seat.

Backplane Connection Engagement: Hand-tighten any integrated front panel thumbscrews to secure the card firmly into position and ensure that the multi-pin gold-plated connectors have achieved complete electrical continuity with the backplane.

Field Wiring Mapping: Because this card acts as a translation layer, the existing field wiring remains attached to the legacy Q-Line terminal blocks. The transition chassis internally routes these signals via specialized ribbon or mass-termination cables provided by Emerson.

Grounding Protocols: The migration rack housing must be bonded to the central cabinet structural earth ground or the Ovation system's quiet instrument ground loop. This step is critical to protect the sensitive CMOS logic on the 5X00228G01 card from common-mode electrical noise and static charges.

OVATION 5X00228G01 Product Advantages & Key Features

Cost-Efficient Lifecycle Upgrades: Eliminates the exorbitant financial and operational costs associated with pulling out legacy terminal blocks and running entirely new field wiring to the instruments.

Minimized Plant Downtime: Features a physical plug-and-play migration design that drastically shrinks the time window needed for cold cutovers during scheduled power plant maintenance outages.

Preserved System Diagnostics: Retains original signal tracing and system safety parameters, allowing operators to monitor channel health and detect wire break faults via the upgraded Ovation system software.

Industrial Noise Isolation: Equipped with onboard filtering circuits designed to block ambient high-frequency electromagnetic interference (EMI) typical of industrial turbine and turbine-generator environments.

•
