Woodward 5466-1047 DCS controller module

• Brand
  Woodward
• Model
  5466-1047
• Product Name
  MicroNet TMR (Triple Modular Redundant) Controller
• Country of Origin
  United States
• HS Code
  8537101100
• Dimensions
  254mm×203mm×51mm
• Weight
  2.3 kg
• Operating Temperature
  -45℃ TO +80℃
• Storage Temperature
  -55℃ TO +98℃
• Power Supply
  24 V DC
• Warranty
  12 MONTH
• Product Status
  NEW AND ORIGINAL

Woodward 5466-1047 Product Introduction & Technical Parameters

Input / Output & Communication

1.Control I/O: Supports up to 14 expansion slots for distributed I/O modules

2.Ethernet: Dual 10/100 Mbps ports (TCP/IP, UDP)

3.Serial: RS-232/422/485; supports Modbus RTU/ASCII

4.Protocols: Modbus TCP, OPC, TCP/IP, UDP

5. Power Supply: 24 V DC (18–30 V range)

6.Signal Types: Analog (4–20 mA, 1–5 V), digital (24 V DC), speed sensors

Main Functions

1.Turbine Control: Speed, load, temperature, and pressure regulation for gas/steam turbines

2.Compressor Control: Surge protection, anti-stall, and load sharing for compressor trains

3. Safety Protection: Overspeed, over-temperature, and over-pressure trip logic

4.Data Acquisition: High-speed analog/digital signal logging and trending

5.Communication Gateway: Interfacing with DCS, SCADA, and HMI systems

6.Fault Diagnosis: Automatic fault detection, isolation, and alarm reporting

Product Advantages

1.Ultimate Reliability: TMR design eliminates single points of failure; ideal for continuous processes

2.Safety Critical: SIL 3 certified; meets strict industry safety standards

3. High Performance: MPC5200 processor delivers fast, deterministic control

4.Seamless Integration: Multi-protocol support enables easy connection to plant-wide systems

5.Reduced Downtime: Hot-swap capability; online maintenance without shutdown

6.Proven in Field: Extensive deployment in power, oil & gas, and petrochemical industries

Application Cases

1.Power Generation: Control and protection of gas/steam turbines in combined-cycle power plants

2.Oil & Gas: Compressor control and surge protection in natural gas transmission and processing

3.Petrochemical: Turbine-driven compressors for ethylene, ammonia, and refining processes

4.Industrial Utilities: Critical turbine and compressor control in large manufacturing facilities

5.Renewable Energy: Hybrid power plants with gas turbine backup and grid stabilization

Key Characteristics

1.TMR Redundancy: Three identical control channels with 2oo3 voting; SIL 3 compliant

2.High Reliability: 99.999% availability; built-in extensive self-diagnostics

3.Open Architecture: Easy integration with HMIs, DCS, and third-party devices

4.Environmental Rating: Operating: -20 °C to +60 °C; Humidity: 5–95% non-condensing

5.Safety Certification: IEC 61508 SIL 3; ATEX, CE marked

6.Real-Time Determinism: Fixed-cycle control for fast, consistent response
