PM803F BDH000530R1 ABB DCS base unit controller

• Brand
  ABB
• Model
  PM803F
• Order Number
  3BDH000530R1
• Product Name
  Base Unit Controller
• Country of Origin
  Sweden
• HS Code
  8537109100
• Dimensions
  164mm × 125mm × 70mm
• Weight
  1.6kg
• Operating Temperature
  10℃ to 25℃
• Storage Temperature
  -25℃ to 38℃
• Warranty
  12 month
• Product Status
  new and original

ABB PM803F Detailed Introduction and Technical Parameters

1.Input specification: Digital input (up to 32 channels), analog input (up to 8 channels), Ethernet/CAN/PROFIBUS communication input;

2.Output specification: Digital output (up to 32 channels), analog output (up to 8 channels), Ethernet communication output, system status and fault alarm output;

3.Power supply requirement: 24VDC ±20% auxiliary power, low power consumption for long-term continuous operation in industrial control cabinets;

Main Functions

1. Serves as the core control unit for AC800F DCS, executing real-time logic, program scheduling, and system coordination;

2. Performs high-speed data acquisition and processing of analog/digital signals from field sensors and actuators;

3. Enables multi-protocol communication for seamless integration with PLC, SCADA, and third-party automation devices;

4.Supports modular I/O expansion to adapt to diverse industrial process control requirements;

5. Conducts system fault diagnosis, real-time status monitoring, and remote maintenance via built-in web server;

6. Ensures deterministic process control with high reliability for mission-critical automation environments.

Industrial Application Cases

1.Power generation industry: Thermal, hydro, and renewable energy power plant DCS core control units;

2.Metallurgical industry: Rolling mill, smelting furnace, and continuous casting process control systems;

3.Chemical industry: Reaction kettle, pipeline, and distillation column process monitoring and control systems;

4.Water treatment: Sewage treatment plant automatic control and monitoring systems;

5.Food and beverage: Production line automation, packaging process control, and quality monitoring systems.

Product Features

1.High-performance 800MHz ARM Cortex A8 processor for fast logic calculation and data processing;

2. Large memory: 512MB DDR3 RAM, 4GB eMMC Flash for program and data storage;

3.Multi-protocol communication: Modbus RTU/TCP, IEC 60870-5-101/104, DNP3, OPC UA for seamless system integration;

4.Modular design: Supports PM8M22/PM8M26 expansion modules for flexible I/O extension;

5.Network redundancy: Dual Ethernet ports for redundant communication and high system availability;

6.Wide operating temperature (-25°C to +70°C) and industrial-grade EMI resistance;

7.Built-in web server for remote diagnostics and maintenance via standard browsers.

•
