ABB 3BHE032593R0002 IPS21-24V-UL Detailed Introduction and Technical Parameters
Technical Parameters
1. Input specification:
85-265VAC wide-range AC input, 50/60Hz frequency adaptation;
2.Output specification:
24VDC ±1% stable DC output, 21A rated current, adjustable 21.6-28.8VDC range ;
3.Power supply requirement:
AC-DC switching power supply design, high efficiency, low power consumption, suitable for long-term continuous operation in industrial control cabinets;
Main Functions
1.Converts wide-range AC power to stable 24VDC auxiliary power for medium-voltage drive control circuits;
2.Supplies power to IGCT/IGBT gate drivers, control boards, and protection units in ACS2000 series drives;
3.Provides overload and short-circuit protection to prevent damage to connected control components;
4. Monitors output voltage and current in real time, triggering alarms for abnormal conditions;
5.Ensures uninterrupted auxiliary power for critical drive systems during main power fluctuations.
Industrial Application Cases
1.Medium-voltage drive systems: ABB ACS2000 series drives for industrial motor control;
2.Power generation industry: Thermal and hydropower plant auxiliary drive power supply systems;
3.Metallurgical industry: Rolling mill and smelting furnace medium-voltage drive control units;
4.Oil and gas industry: Pipeline compressor and pump medium-voltage drive systems;
5.Renewable energy: Wind farm and solar power station grid-connected converter control power supply.
Product Features
1.Wide-range AC input (85-265VAC) for global industrial power grid adaptation;
2.High-precision 24VDC output with ±1% voltage regulation, ensuring stable control power ;
3.Integrated multi-level protection: overvoltage, overcurrent, short-circuit, and overtemperature protection;
4.Rugged metal enclosure with high resistance to vibration, dust, and electromagnetic interference;
5.Compact modular design for easy installation and replacement in standard drive cabinets;
6.UL certification for safety compliance in industrial applications;
7. Wide operating temperature range (-20°C to +60°C) for harsh industrial environments.
