5SHX2645L0004 3BHL000389P0104 ABB industrial IGCT

• Brand
  ABB
• Model
  5SHX2645L0004
• Order Number
  3BHL000389P0104
• Product Name
  IGCT Power Semiconductor Module
• Country of Origin
  Switzerland
• HS Code
  8541900000
• Dimensions
  150mm × 130mm × 40mm
• Weight
  1.5kg
• Operating Temperature
  10℃ to 35℃
• Storage Temperature
  -15℃ to 36℃
• Warranty
  12 Month
• Product Status
  New and original

ABB 5SHX2645L0004 3BHL000389P0104 Detailed Introduction and Technical Parameters

1.Input specification:
Optical fiber gate trigger signal input, control power signal input, built-in temperature sensor signal input and internal detection feedback signal input;

2.Output specification:
High-power main circuit power switching output, real-time module operating status signal output, fault alarm signal output and system protection feedback output;

3.Power supply requirement:
External 24 VDC auxiliary control power supply for internal drive and monitoring circuit, medium voltage high DC power supply for main power conversion circuit;

Main Product Functions:

1.Acts as the core power switching component for medium voltage high-power inverters, converters and rectifier equipment;

2.Realizes efficient AC-DC and DC-AC energy conversion and precise power regulation for industrial electrical systems;

3.Provides automatic overcurrent protection, overvoltage protection and overtemperature protection to avoid module damage and system failure;

4.Monitors real-time internal operating temperature and working status to support system fault diagnosis and early warning maintenance;

5.Supports parallel connection and combined use of multiple modules to meet higher power industrial equipment operation requirements;

6.Cooperates with industrial control and DCS systems to realize stable and controllable high-power electric drive operation.

Industrial Application Cases:

1.Thermal power and hydropower plant medium voltage frequency conversion drive and power grid energy regulation projects;

2.Metallurgical steel industry rolling mill main drive system and smelting furnace high-power power supply control system;

3.New energy wind power and solar power station grid-connected high-power converter and energy storage power conversion equipment;

4.Marine and offshore engineering platform high-power electric propulsion and power distribution management system;

5.Mining heavy machinery medium voltage motor drive system and large industrial high-power frequency conversion speed regulation projects.

Product Features:

1.Adopts advanced IGCT chip technology with ultra-high rated current and high voltage withstand capability;

2.Designed with extremely low conduction loss and switching loss to improve overall system energy efficiency;

3.Built-in integrated drive unit, monitoring circuit and multi-level safety protection structure inside the module;

4.Excellent heat dissipation structure design, compatible with water cooling and air cooling industrial heat dissipation systems;

5.Strong anti-electromagnetic interference performance, suitable for high-noise and heavy industrial power working environment;

6.Rugged sealed industrial module packaging, high mechanical strength and long service life for continuous operation;

7.Compact modular structure, convenient installation, replacement and maintenance inside high-power converter cabinets.
