PP865 ABB DCS 15-inch TFT touchscreen HMI

• Brand
  ABB
• Model
  PP865
• Order Number
  3BSE042236R1
• Product Name
  15-inch Touchscreen Operator HMI Panel
• Weight
  3.7 kg
• Original
  Switzerland
• Customs HS
  85371090
• Dimensions
  398 mm (W) x 304 mm (H) x 6 mm (D)
• Operating Temperature
  -25°C to +60°C
• Storage Temperature
  -40°C to +85°C
• Warranty
  12 month
• Product Status
  New and original

ABB PP865 Panel 800 Operator Touch Panel HMI Product Introduction

Input

Display: 15-inch TFT-LCD, 64K colors, 1024 x 768 resolution

Touch interface: Resistive touchscreen, rated for ≥1 million touches

Processor: 32-bit RISC CPU (100 MHz)

Memory: 128 MB RAM, 256 MB flash memory

Communication ports:

RS-232 (9-pin D-sub)

RS-422/RS-485 (25-pin D-sub)

Ethernet (RJ-45)

USB 1.1 (Type A host, Type B device)

CompactFlash (CF) card slot

Output

Visualization: High-fidelity color graphics, trend charts, alarm displays

Status indicators: Multi-color LEDs for power, operation, faults, and communications

Control outputs: Configurable virtual control keys and touch-activated commands

Protocol support: Modbus RTU/TCP, Profibus DP, Ethernet/IP, ABB SattBus

Power Requirements

Supply voltage: 24 V DC (20–30 V DC range)

Power consumption: Approximately 28.8 W (1.2 A @ 24 V DC)

Isolation: 2500 V AC power/signal isolation

Core Functions

Real-time process monitoring and graphical visualization

Intuitive touch-based operation and parameter adjustment

Alarm management, event logging, and trend analysis

Recipe management and batch process control

User authentication and access permission control

Remote configuration, firmware updates, and diagnostics

Data exchange with PLCs, DCS, and other industrial controllers

Key Features

Rugged aluminum alloy construction with powder-coated rear casing

Front panel IP66, rear IP20 environmental protection

Wide operating temperature range for extreme industrial settings

Shock and vibration resistance (6 G, 10–2000 Hz)

EMC compliance with IEC 61000-4 standards

Certifications: CE, UL, cUL, ATEX, and Class I Div 2 hazardous location approvals

Hot-swappable communication modules (select configurations)

Multi-language support for global operation

Application Cases

Oil & Gas: Process control and monitoring in refineries, offshore platforms, and pipeline systems

Power Generation: Turbine control, boiler management, and substation automation

Chemical & Petrochemical: Reactor control, material handling, and safety system interfacing

Water & Wastewater: Treatment plant monitoring, pump control, and distribution management

Manufacturing: Assembly lines, robotics control, and packaging machinery operation

Metals & Mining: Furnace control, material processing, and conveyor systems

Marine & Offshore: Vessel automation, drilling rig control, and FPSO systems

Food & Beverage: Batch processing, packaging lines, and sanitary environment operation

Pharmaceuticals: Cleanroom automation, regulatory-compliant process control

Key Advantages

Industrial ruggedness: IP66 front protection against dust, water, and oil for harsh environments

High visibility display: Crisp 1024x768 resolution for clear process visualization

Fast, reliable touch: Durable resistive touch with long operational life

Flexible connectivity: Multiple serial, Ethernet, and USB interfaces for broad system integration

Seamless integration: Fully compatible with ABB 800xA, AC 800M, and Panel Builder 800 software

Advanced diagnostics: Built-in self-testing and real-time system health monitoring

Long-term reliability: High MTBF and industrial-grade components for continuous operation

•
  PP865 PDF
  Download
