S-093H 3BHB030478R0009 ABB power supply module

• Brand
  ABB
• Model
  S-093H
• Order Number
  3BHB030478R0009
• Product Name
  MV Drive Phase Module (Active Rectifier Unit)
• Country of Origin
  Switzerland
• HS Code
  85049099
• Dimensions
  850 mm*550 mm*650 mm(H* W*D)
• Weight
  150 kg (330.7 lbs)
• Operating Temperature
  -20 °C to +60 °C
• Storage Temperature
  -30°C to +80 °C
• Warranty
  12 month
• Product Status
  new and original

ABB S-093H 3BHB030478R0009 Product Introduction

Technical Specifications

1.Input: 3.3 kV-6.6 kV AC (3‑phase, 50/60 Hz); rated current 400–800 A

2.Output: DC link voltage up to 9.3 kV; supports 1-3 kHz switching frequency

3.Power Supply: 24 V DC (gate drive); independent GUSP (Gate Unit Power Supply) per phase

4.Cooling Method: Water‑cooled (high heat dissipation for high power density)

5.Protection Class: IP20 (cabinet installation); G3 coated for corrosion resistance

6.Certifications: CE, UL, cUL, RoHS compliant; EMC compliant (EN 61000-6-2, EN 61000‑6‑4)

Product Advantages

1.Ultra‑High Efficiency: ≥98% power conversion efficiency minimizes energy consumption and operational costs.

2.Superior Performance: Fast dynamic response (millisecond‑level) handles heavy, variable loads in mining, rolling mills, and HVAC systems.

3.Robust Reliability: Industrial‑grade components, G3 coating, and water cooling ensure stable operation in dusty, humid, or corrosive environments.

4.Simplified Maintenance: Hot‑swap compatible and equipped with diagnostic LEDs for quick troubleshooting and reduced downtime.

5.Scalable & Future‑Ready: Compatible with ABB ACS6000 MV drives and scalable for 3–36 MW applications, protecting long‑term investments.

Key Features

1.Advanced IGCT Technology: Combines IGBT high-speed switching and GTO high blocking voltage/low conduction loss for superior efficiency and reliability.

2.High Power Density: Integrates IGCTs, diodes, and clamping capacitors in a compact, water-cooled design for 3-36 MW power ranges.

3.Fiber-Optic Triggering: Ensures fast, noise-immune signal transmission to IGCT units for precise synchronization.

4.Multi-Level Topology: Reduces harmonic distortion (THDi < 5%) and improves power quality for grid-friendly operation.

-5.Comprehensive Protection: Integrates overvoltage, overcurrent, short-circuit, and overtemperature protection with real-time diagnostics.

6. Modular & Redundant: Supports parallel operation and redundant configurations for enhanced system availability.

•
  S-093H 3BHB030478R0009 PDF
