12HEA61A224X2 GE auxiliary relay NEW BRAND

• Brand
  GE
• Model
  12HEA61A224X2
• Product Name
  Lockout Auxiliary Relay
• Operating Voltage
  125 V DC
• Contact Configuration
  Multi-contact design
• Coil Power Dissipation
  2 W
• Current Handling
  2 A
• Dimensions
  100 mm*75 mm*60 mm(W*H*D)
• Weight
  0.5 kg
• Operating Temperature
  -30 °C to +85 °C
• Storage Temperature
  -40 °C to +90 °C
• Protection Rating
  IP20

Basic Specifications:

Operating Voltage: 125 V DC

Contact Rating: 5 A resistive load

Coil Power Consumption: 2 W typical

Mounting: Panel mount

Protection Rating: IP20

Dimensions: Approx. 100 mm *75 mm *60 mm (W* H *D)

Weight: Approx. 0.5 kg

Operating Temperature: -30°C to +85°C

Storage Temperature: -40°C to +90°C

Humidity: 5%–95% non-condensing

Compliance: IEC 60694, IEEE C37

Core Functions:

1.Provides lockout signaling for power protection systems

2.Delivers reliable status feedback for protective relays

3.Controls auxiliary circuits in power distribution and substations

4.Ensures safe isolation and indication of system fault conditions

5.Supports interlocking and logic control in electrical protection schemes

Product Advantages:

1.High reliability for 24/7 continuous industrial operation

2.Clear visual status indication reduces troubleshooting time

3.Easy installation and direct replacement minimizes downtime

4.Wide temperature range adapts to harsh on-site environments

5.Complies with global industrial standards for universal application

6.Stable contact switching ensures long-term maintenance-free use

Typical Applications:

1.Substation protection and control systems

2.Power distribution network switchgear

3.Industrial power monitoring and safety interlocks

4.Generator and motor protection auxiliary circuits

5.Electrical fault lockout and status indication systems

Key Features:

1.Manual reset with mechanical visual flag for clear trip/reset status

2.Multi-contact configuration for flexible auxiliary circuit wiring

3.Rugged industrial construction for harsh substation environments

4.Standard HEA61 series footprint for direct drop-in replacement

5.Stable contact performance with long mechanical and electrical life

6.Excellent anti-vibration and shock resistance
