DS200TCPDG1B GE DCS I/O board

• Brand
  GE
• Model
  DS200TCPDG1B
• Order Number
  DS200TCPDG1B
• Product Name
  Power Distribution Module
• Origin
  United States of America
• Customs Code
  85371090
• Dimensions
  304.8mm (H) * 213.3mm (W)* 25mm (D)
• Weight
  Approx. 0.65kg
• Operating Temperature
  -40°C to +70°C
• Storage Temperature
  -55°C to +85°C
• Warranty
  12-month
• Condition
  New and original

GE DS200TCPDG1B Product Introduction  and Technical Parameters

Technical Parameters

1.Power Input: 125V DC primary distribution; 115/230V AC external auxiliary power

2. Power Output: Regulated 5V DC, 24V DC, 125V DC for system cores

3.Power Consumption: Max. 8.5W

4.Fuse Configuration: 36 individually fused output circuits (labeled FU1–FU36)

5.Control Switches: 8 toggle switches for independent core power control

6. Terminals: 4 signal wire terminals (AC1N, AC1H, AC2N, AC2H); 1×10-pin connector

7.Indicators: 36 green OK LEDs (fuse status); 2 red LEDs (board fault)

8.Isolation Voltage: 2500V AC (input/output isolation)

9. Certifications: CE, UL, ATEX Zone 2, API 670 compliant

10.Mounting: Rack-mounted in Mark V control panel PD core

Product Advantages

1.Ensures stable, protected power delivery for critical turbine control functions

2.Rapid fuse fault identification via dedicated OK LEDs to minimize downtime

3.Enhanced system safety with isolated power paths and redundant protection

4.Robust construction for continuous operation in harsh industrial environments

5.Direct replacement for legacy Mark V power distribution boards (backward compatible)

6.Simplified wiring with clearly labeled terminals and secure screw connections

Key Functions

1.Primary power distribution for Mark V control system cores

2.Overcurrent and short-circuit protection for all output circuits

3.Real-time status monitoring and fault indication

4.Manual core power isolation for maintenance

5.Signal power routing and terminal connection for auxiliary systems

Typical Applications

1.Gas turbine control systems (power generation, mechanical drive)

2.Steam turbine speed/load regulation and protection

3.Industrial power generation plants (combined cycle, thermal)

4.Oil & gas pipeline compression stations

5.Turbine control retrofits and legacy system modernization

6. Critical power generation and industrial automation facilities

Product Features

1.Industrial-grade power distribution module for GE Speedtronic Mark V turbine control systems

2.Distributes 125V DC power to control engine, I/O (TCPS), and emergency overspeed (TCEA) cores

3. Comprehensive circuit protection via 36 fuses with real-time LED status monitoring

4.8 manual toggle switches for safe, individual power control of system cores

5. Built-in fault detection with red LED alerts for board-level malfunctions

6.Rugged PCB design with conformal coating for high vibration and EMI resistance

7. Hot-swappable design for maintenance without full system shutdown

8.Fully compatible with TMR (Triple Modular Redundant) Mark V architectures
