3625 Triconex digital output module new in stock

• Brand
  Triconex
• Model
  3625
• Product Name
  Supervised Digital Output Module
• Weight
  1.2 kg
• Dimensions
  85 mm x 140 mm x 120 mm
• Original
  United States
• Customs HS
  85389091
• Operating temperature
  -40°C to 70°C
• Storage temperature
  -55°C to 85°C
• Warranty
  12 month
• Input
  24 VDC (18–32 VDC)
• Product Status
  new and original

Triconex 3625 Supervised Digital Output Module Product Introduction

Input

Input Voltage: 24 VDC (18–32 VDC)

Power Input: Backplane-powered from Tricon system chassis

Output

Output Type: 32-channel 24 VDC supervised digital output

Output Current: 1.7 A per channel (maximum), 10 mA minimum load

Isolation: 1500 VDC channel-to-channel and channel-to-backplane

Output Modes: Configurable for supervised or non-supervised operation

Voltage Drop: <2.8 VDC at rated current

Power Requirements

Module Power Consumption: Approximately 30 W

Operating Voltage: 24 VDC nominal (supplied by system backplane)

Core Functions

1.Executes safety system commands to drive critical field devices including valves, pumps, motors, and alarm circuits.

2.Provides continuous supervision of output circuits to detect open loads, short circuits, and wiring faults.

3.Performs real-time voting of three independent output signals to ensure accurate and fault-free control.

4.Supports online module replacement without system shutdown (hot-swappable).

5.Generates time-stamped sequence-of-events (SOE) logs for audit and troubleshooting.

Key Features

1.Full Fault Isolation: Each channel is electrically isolated to prevent cross-channel faults.

2.Overvoltage & Short-Circuit Protection: Built-in protection safeguards against electrical anomalies.

3.MTBF > 2,000,000 Hours: Exceptional mean time between failures for maximum operational reliability.

4.Flexible Configuration: Software-configurable for supervised or non-supervised output modes.

5.Wide Compatibility: Seamlessly integrates with Tricon v9–v10 safety systems and supports Modbus TCP/IP communication.

6.Industry Approvals: SIL 3, ATEX, FM, CE, and cUL certifications.

Application Cases

Oil & Gas Refineries: Controls emergency shutdown valves and burner management systems to prevent explosions and fires.

Petrochemical Plants: Manages safety interlocks for reactor systems, pipeline isolation, and gas detection responses.

Power Generation: Implements turbine protection, boiler safety, and emergency feedwater pump control.

Offshore Platforms: Operates under extreme conditions to control safety valves, fire suppression, and gas release systems.

Chemical Processing: Drives critical shutoff valves and safety interlocks in polymer and specialty chemical production.

Nuclear Power Facilities: Supports non-reactor safety systems requiring SIL 3 reliability.

Key Advantages

1.TMR Architecture: Triple modular redundant design with majority voting ensures no single point of failure, delivering 99.999% system availability.

2.SIL 3 Certification: Complies with IEC 61508 SIL 3 standards for critical safety applications.

3.Advanced Diagnostics: Comprehensive online diagnostics monitor each output channel, field wiring, and load status, providing real-time fault alerts.

4.Fault-Tolerant Design: Quadruplicated output switches ensure fail-safe operation and continued performance during component faults.

5.Harsh Environment Rating: Operates reliably in extreme temperatures, high vibration, and electromagnetic interference.

6.High Channel Density: 32 output channels reduce cabinet space requirements and overall system cost.
