XV-303-15-C00-A00-1C EATON DCS touch HMI

• Brand
  EATON
• Model
  XV-102-D0-57TVR-10
• Product Name
  Industrial Touch Screen HMI
• Country of Origin
  United States
• Dimensions
  130 mm (W) x 39 mm (H) x 170 mm (D)
• HS Code
  85371090
• Weight
  0.54 kg (1.19 lbs)
• Operating temperature
  0°C to +55°C
• Storage temperature
  -40°C to +70°C
• Power Supply
  24 V DC
• Warranty
  12 month
• Product Status
  New and original

EATON XV-303-15-C00-A00-1C Industrial Touch Screen HMI (XV100 Series)

Technical Parameters

Relative Humidity: 5–95% RH (non-condensing)

Power Supply: 24 V DC (18–32 V DC wide range)

Power Consumption: ≤ 5 W (fanless, passive cooling)

Protection Rating: Front panel IP65; Rear side IP20

Display: 5.7-inch TFT color LCD, VGA resolution (640 x 480 pixels)

Touch Technology: 4-wire resistive touch screen, high sensitivity for glove operation

Display Colors: 64,000 colors (16-bit)

Backlight: LED backlight, lifespan ≥ 50,000 hours

Processor: 32-bit high-performance RISC processor (400 MHz)

Memory: 64 MB DRAM, 128 MB Flash memory

Expansion: 1 x SD card slot (supports up to 32 GB SDHC card)

Communication Interfaces:

1 x Ethernet 10/100 Mbps (RJ45)

1 x RS-232

1 x USB Device (for programming)

1 x USB Host (for peripherals)

Protocol Support: Modbus RTU, Modbus TCP, Ethernet/IP, Profibus DP (optional), CAN open

Isolation: 2500 V AC signal-to-system isolation

Certifications: CE, UL 508, cULus, IEC/EN 61000-6-2/6-4, RoHS

Mounting: Flush panel mounting (control cabinet/console)

Enclosure Material: High-strength industrial plastic (ABS/PC blend)

Operating System: Windows CE 5.0

Configuration Software: EATON Galileo (dedicated HMI programming software)

Product Features

Industrial-Grade Ruggedness: IP65 front protection against dust, water splashes, and oil; robust construction for harsh plant environments.

Fanless Passive Cooling: No moving parts for enhanced reliability, reduced maintenance, and extended service life.

High-Visibility Display: Crisp 5.7-inch TFT color display with LED backlight for clear readability in varying ambient light conditions.

Resistive Touch Sensitivity: Responsive 4-wire resistive touch supports operation with bare hands or work gloves.

Versatile Connectivity: Rich I/O and communication ports for seamless integration with PLCs, drives, and other automation devices.

Flexible Memory Expansion: SD card slot for data logging, project backup, and application expansion.

Intuitive Software: Galileo software enables easy screen design, logic programming, and system configuration.

Wide Compatibility: Supports all major industrial communication protocols for multi-vendor system integration.

Compact & Space-Saving: Slim profile design optimizes panel space in control cabinets.

High Electromagnetic Compatibility: Superior EMC performance for stable operation in electrically noisy environments.

Long-Term Reliability: Industrial-grade components with high MTBF and low failure rates.

Core Functions

Real-Time Process Visualization: Displays dynamic process data, mimic diagrams, trends, and alarm statuses in real time.

Touch Control & Parameter Setting: Enables operators to adjust setpoints, start/stop equipment, and modify system parameters via touch input.

Data Acquisition & Logging: Collects, stores, and exports process data to SD card or connected systems for analysis.

Alarm & Event Management: Generates visual and audible alarms, logs events, and displays fault codes for rapid troubleshooting.

Remote Monitoring & Control: Supports remote access via Ethernet for off-site system monitoring and control.

Multi-Language Support: Offers multi-language interface customization for global operations.

System Diagnostics: Provides built-in self-diagnostics to monitor HMI health, communication status, and I/O integrity.

Recipe Management: Stores and manages production recipes for quick product changeovers in manufacturing processes.

Typical Application Cases

Manufacturing Automation: Machine tool control, assembly line monitoring, and packaging machinery operation.

Power Generation: Boiler control, turbine monitoring, and power plant auxiliary system management.

Oil & Gas: Refinery process control, pipeline monitoring, and wellhead automation.

Water & Wastewater: Treatment plant process control, pump station operation, and SCADA integration.

Food & Beverage: Batch processing, packaging line control, and sanitary environment-compliant operation.

Chemical & Pharmaceutical: Reactor control, material batching, and hazardous area monitoring.

Mining & Metals: Crushing, grinding, and material handling equipment control.

Building Automation: HVAC control, energy management, and facility monitoring systems.

Key Advantages

Proven EATON Reliability: Field-proven design for continuous operation in demanding industrial conditions.

Seamless System Integration: Plug-and-play compatibility with EATON and third-party automation components.

Reduced Total Cost of Ownership: Low power consumption, minimal maintenance, and long service life.

Enhanced Operational Efficiency: Intuitive touch interface reduces operator training time and human error.

Future-Proof Technology: Scalable architecture supports software updates and communication protocol expansions.

Global Compliance: Certified to international safety and EMC standards for worldwide deployment.

Flexible Configuration: Easily adaptable to diverse application requirements with customizable screen layouts.

Robust Environmental Resistance: Wide temperature tolerance and high protection ratings for harsh industrial settings.

•
