2RAA005697M ABB DCS contactor MODULE

• Brand
  ABB
• Model
  2RAA005697M
• Input
  24 V DC
• Product Name
  DCS Communication Processor Module
• Country of Origin
  Sweden
• HS Code
  85371011
• Dimensions
  80 mm*120 mm * 30 mm(H * W * D)
• Weight
  0.8 kg
• Operating Temperature
  -40 °C to +70 °C
• Storage Temperature
  -40 °C to +85 °C
• Warranty
  12 MONTH
• Product Status
  New and original

ABB 2RAA005697M Product Introduction

Technical Specifications

1.Communication Interfaces: Multi-channel (including RS-485, Ethernet; supports IEC 61850, Modbus RTU/TCP protocols)

2.Baud Rate: Up to 10 Mbps (configurable)

3. Input: 24 V DC (19.2-32.5 V DC range); digital signal input (22 mA)

4.Output: Digital signal output (12 mA); supports relay and transistor outputs

5. Power Supply: 24 V DC; power consumption ≤ 2.5 W

6. Humidity: 5-95% (non‑condensing)

7.Protection Class: IP20

Product Advantages

1.Simplified System Integration: Eliminates the need for additional gateways, reducing hardware complexity, wiring effort, and integration costs.

2.High Reliability & Stability: Industrial‑grade components and strict quality control minimize downtime, ensuring continuous and stable operation of critical processes.

3.Scalable Performance: Supports large‑scale data transmission and device connectivity, adapting to small-to-large industrial automation projects.

4.Easy Configuration & Maintenance: Fully configurable via ABB engineering software; user-friendly diagnostic features reduce maintenance time and costs.

5.Long-Term Compatibility: Backward-compatible with ABB DCS systems and software updates, protecting investment in existing automation infrastructure.

Key Features

1.High-Speed Multi-Protocol Communication: Supports mainstream industrial protocols (IEC 61850, Modbus), enabling seamless integration with diverse devices and systems.

2.Robust Industrial Design: Wide temperature tolerance and IP20 protection ensure reliable operation in vibration, dust, and moisture-prone industrial environments.

3.Powerful Data Processing: Equipped with a high-performance processor and large-capacity memory (3213 Mb), enabling efficient data calculation, processing, and transmission.

4.Diagnostic & Monitoring: Integrated LED indicators for power, communication status, and fault detection, facilitating real‑time monitoring and quick troubleshooting.

5.Compact & Modular: Space-saving design optimizes cabinet layout; supports hot-swap for easy installation and replacement without system shutdown.
