ABB CS513 3BSE000435R1 Communication Processor Module

• Brand
  ABB
• Model
  CS513
• Product Name
  Profibus FMS Communication Processor Module
• Country of Origin
  Sweden
• HS Code
  8538900000
• Dimensions
  234mm×108mm×18mm
• Weight
  0.21 kg
• Operating Temperature
  -20℃ to +120℃
• Storage Temperature
  -30℃ to +80℃
• Part Number
  3BSE000435R1
• Warranty
  12 month
• Product Status
  New and original

ABB CS513 3BSE000435R1 Product Introduction & Technical Specification

Electrical Input & Output Parameter

1.Power Input: Powered via rack backplane (5VDC, ±15VDC internal bus power supply)

2.Rated Power Consumption: ≤ 5.2 W

3.System Backplane Input: Advant Controller internal rack bus interface

4.Field Communication Output 1: MasterBus 300 network port (D-Sub 9 connector, 1.5Mbps)

5.Field Communication Output 2: Profibus FMS RS485 interface

6.Supported Communication Protocols: MasterBus 300E, Profibus FMS, Modbus RTU

7.Max Supported Network Nodes: Up to 32 nodes for MasterBus single segment

8.Profibus Baud Rate: 9.6 kbps ~ 12 Mbps adjustable

9.Communication Response Cycle: ≤ 10ms

10.Debug Interface: Front service pin for parameter configuration and fault diagnosis

Core Product Functions

1.Establish MasterBus 300 high-speed industrial network for Advant DCS whole-system data interconnection

2.Realize real-time data transmission between main controller CPU and OWP operator monitoring stations

3.Complete Profibus FMS protocol conversion to communicate with third-party intelligent instruments and controllers

4.Execute industrial network traffic management, node address identification and data filtering processing

5.Transmit field process data to upper monitoring system and download control commands from upper system to main CPU

6.Record network communication fault logs, link abnormal records for troubleshooting analysis

7.Cooperate with full series Advant AC400/AC500 modules to construct complete distributed DCS control network

Product Advantages

1.Perfect seamless compatibility with ABB Advant Controller AC400/AC500 series main control units

2.Independent communication operation greatly reduces main CPU load, improving overall system operation efficiency

3.Dual-protocol design realizes internal system networking and third-party equipment docking simultaneously

4.Isolation structure effectively eliminates ground loop interference, ensuring long-term communication stability

5.Hot-swap maintenance minimizes industrial production downtime during module replacement

6.Compact plug-in structure saves cabinet layout space, easy wiring and system expansion

7. Mature stable spare part for old ABB Advant DCS system renovation, overhaul and upgrade

Typical Application Cases

1.Thermal Power Plant DCS System: Unit boiler, turbine auxiliary equipment whole-process network communication and centralized monitoring

2.Pulp & Paper Mill: Production line distributed control system interconnection and workshop equipment linkage control

3.Petrochemical Refinery: Reaction unit process data transmission and safety monitoring network construction

4.Metallurgical Smelting Plant: Rolling mill, sintering equipment distributed signal communication and process control

5.Cement Industry Production Line: Rotary kiln, grinding equipment multi-point centralized network data transmission

6.Municipal Waste Incineration Power Plant: Flue gas treatment equipment interlock communication and operation monitoring control

Product Characteristics

1.Independent dedicated communication processor chip for offloading main CPU network data processing tasks

2.Galvanic isolation between backplane circuit and field communication bus, 1500VAC isolation withstand voltage

3.Front panel LED indicators for power supply, running status, bus link and communication fault alarm

4.Operating temperature range: 0°C ~ +60°C; storage temperature: -40°C ~ +85°C

5.Ambient humidity: 5%~95% non-condensing, IP20 cabinet internal protection grade

6.Standard rack slot plug-in installation, supports hot-plug maintenance without system shutdown

7.Complete hardware self-diagnosis: bus short-circuit, communication interruption, module abnormal detection

8.Strict EMC anti-electromagnetic interference design, conforming to IEC industrial standard

9.Passed CE industrial certification, stable operation under dusty industrial environment

•
