PP875 3BSE092977R1 ABB DCS HMI panel

• Brand
  ABB
• Model
  PP875
• Product Name
  Panel 800 PP875 7-inch Resistive Touch HMI Operator Panel
• Country of Origin
  Sweden
• HS Code
  8471410000
• Dimensions
  204mm×143mm×50mm
• Weight
  1.10 kg
• Operating Temperature
  -20℃ to +80℃
• Storage Temperature
  -30℃ to +100℃
• Part Number
  3BSE092977R1
• Warranty
  12 month
• Product Status
  New and original

ABB PP875 3BSE092977R1 Product Introduction & Technical Specification

Electrical Input & Output Parameter

1.Power Input: 24 V DC (18~32 V DC wide voltage input)

2.Rated Power Consumption: ≤14.4 W

3.Main Processing Unit: ARM9 1GHz industrial processor

4.Memory Configuration: 512MB RAM, 2GB SSD storage (1.5GB available for application)

5.Communication Input Interface: 1×10/100Mbps Ethernet RJ45

6.Serial Communication Port: 1×RS232, 1×RS422/RS485

7.External Expansion Port: 1×USB2.0 host port

8.Supported Communication Protocols: Modbus TCP, Modbus RTU, ABB 800xA internal protocol, Profibus DP

9.Display Parameter: 7-inch TFT LED screen, resolution 800×480, brightness 350 cd/m²

10.Touch Mode: Resistive touch screen

Core Product Functions

1. Real-time display of DCS running parameters: temperature, pressure, flow, frequency, power and equipment operating status

2. Complete on-site manual/automatic switching, valve/pump start-stop remote touch operation

3. Real-time fault alarm pop-up display, alarm classification and sound reminder function

4. Collect, store and export historical trend curve, operation log and fault event records

5. On-line modification of control loop PID parameters, interlock threshold and system setting values

6. Bidirectional data communication with ABB AC800M/800xA main controller and multi-brand PLC equipment

7. Support multi-level user password authority management to prevent unauthorized operation

8. Project configuration download, program debugging via USB and Ethernet ports

Product Advantages

1.Perfect seamless compatibility with full ABB 800xA DCS platform, zero communication matching problem

2.Rich industrial communication protocols, flexible connection with third-party automation equipment

3. Rugged front panel adapts to dusty, humid, vibrating industrial field environment

4. High-resolution wide-angle display, clear viewing under strong light working condition

5. Configuration by ABB Panel Builder 800 software, simple programming and easy maintenance

6. Long service life, low failure rate for 24/7 uninterrupted industrial operation

7. Standard replacement spare part for old ABB automation system HMI renovation and upgrade

Typical Application Cases

1.Thermal Power Plant: Boiler, turbine auxiliary equipment centralized monitoring and local operation control

2.Petrochemical Refinery: Reaction unit, pipeline process parameter monitoring and safety operation management

3.Metallurgical Industry: Smelting workshop production line equipment status monitoring and sequential operation control

4.Cement & Building Material Plant: Rotary kiln, grinding equipment full-process operation monitoring

5.Water Treatment Plant: Sewage dosing pump, fan linkage control and online data monitoring

6.Offshore & Marine Automation: Marine power system, vessel auxiliary equipment local operation HMI terminal

Product Characteristics

1. Aluminum alloy powder-coated housing, front IP65/NEMA4X protection grade, rear IP20

2. Wide operating temperature: -10°C ~ +60°C; storage temperature: -20°C ~ +70°C

3. Ambient humidity 5%~85% non-condensing, anti-vibration industrial standard compliance

4. Embedded Windows Embedded CE 6.0 stable operating system

5. Complete hardware self-diagnosis, power reverse connection, overvoltage protection

6. Support panel embedded installation and VESA 75×75 bracket installation

7. Passed CE, UL, DNV marine & industrial certification, RoHS compliant

8. Real-time clock function, offline data storage and power-off data retention

•
