Description
-
BrandABB
-
ModelPFSA103D
-
Product NameHigh-Precision Tension Measurement & Control Module
-
Country of OriginSwitzerland
-
HS Code85423190
-
Dimensions118mm×80mm×36mm
-
Weight0.78kg
-
Operating Temperature-10℃ to +60℃
-
Storage Temperature-40℃ to +85℃
-
Part Number3BSE002492R1
-
Warranty12 month
-
Product StatusNew and original
ABB PFSA103D (3BSE002492R1) Product Introduction & Technical Specifications
Input and Output Parameters
Power Input: 24VDC industrial power supply with ±15% tolerance, maximum power consumption ≤ 5W, low energy consumption
Signal Input: Dedicated Pressductor magnetic pressure sensor signal input, supporting high-sensitivity tension signal collection
Signal Output: Standard configurable 4-20mA current or 0-10V voltage analog output for upper system closed-loop tension control
Communication Interface: Equipped with RS232 and RS485 interfaces, supporting Modbus industrial communication protocol for data transmission and parameter debugging
Control Performance: High control accuracy up to ±0.1%, fast response time less than 10ms, realizing real-time dynamic tension adjustment
Wiring Mode
It adopts front screw terminal wiring design with clear signal and power marking to avoid wiring errors. Independent terminals are configured for sensor signal input, power supply and analog signal output respectively. It supports on-site hard wiring for direct connection with tension sensors and upper control equipment. Shielded cables are recommended for sensor and analog signal wiring to eliminate external signal interference and guarantee measurement accuracy.
Compatibility & Matching Accessories
It is perfectly compatible with ABB Pressductor series tension sensors and industrial automation control systems. It can be matched with ABB PLC and DCS systems to form a complete tension closed-loop control system. Standard supporting accessories include dedicated DIN mounting guide rails, fixed fasteners, terminal insulating baffles and signal shielding terminals. It supports original ABB accessories and qualified third-party compatible accessories for equipment installation, maintenance and system upgrading.
Application Scenarios
It is mainly applied to high-precision tension monitoring and closed-loop control in winding and unwinding production processes. Widely used in papermaking, textile, plastic film, wire and cable, and printing industries. It is also applicable to tension control of strip materials in metallurgy and rubber industries, effectively stabilizing production tension, preventing material deviation, stretching and breaking, and improving overall production efficiency and product quality.
Core Product Advantages
This module delivers industry-leading high-precision tension detection and stable control performance, effectively avoiding material tension deviation and production defects. It features ultra-fast signal response to adapt to high-speed winding and unwinding production lines. Low-power design reduces long-term operating energy consumption. Industrial-grade anti-interference circuit ensures stable signal acquisition under complex electromagnetic environments. Compact modular design saves cabinet space and supports flexible installation methods. It supports precise closed-loop tension adjustment, greatly improving product yield and production consistency, with excellent long-term operating stability and durability.
