CVMI2B 3BHE037864R0101 ABB DCS control board

• Brand
• Model
• Product Name
• Country of Origin
• HS Code
• Dimensions
• Weight
• Operating Temperature
• Storage Temperature
• Part Number
• Warranty
  12 month
• Product Status
  New and original

ABB CVMI2B 3BHE037864R0101 Product Introduction & Technical Specifications

Input and Output Parameters

Power Input: 24VDC industrial power supply with ±20% tolerance, maximum power consumption ≤ 9.8W

Signal Input: Supports multi-channel AC/DC voltage sampling signals and standard industrial digital switching signals for real-time system voltage monitoring

Signal Output: Isolated analog feedback signals and digital status output signals for upper system data acquisition and fault judgment

Communication Interface: Equipped with dedicated bus interface, supporting ABB internal dedicated protocol and standard Modbus communication

Isolation Performance: 2500VAC dielectric isolation between power and signal circuits, effectively resisting industrial electromagnetic interference

Wiring Mode

It adopts dual standard wiring designs. Front screw terminal wiring is used for on-site hard connection of monitoring signals with clear polarity marks to avoid wiring errors. Backplane plug-in wiring supports integrated cabinet installation, realizing one-step power supply and bus signal connection. Shielded cables are recommended for voltage signal wiring to improve signal stability and anti-interference ability.

Compatibility & Matching Accessories

It is fully compatible with ABB mainstream excitation control modules and DCS automation systems, capable of supporting the normal operation of complete power generation control systems. Standard supporting accessories include dedicated mounting guide rails, terminal insulating baffles, original connecting terminals and backplane adapter plates. It supports both original ABB accessories and qualified third-party compatible accessories for system installation, renovation and upgrade.

Application Scenarios

It is mainly applied to voltage monitoring and signal matching of generator excitation systems in thermal power, hydropower and gas turbine power plants. It is also widely used for operating voltage detection and signal transmission of high-power industrial equipment in metallurgy, mining and cement industries. Additionally, it serves as a key signal monitoring unit for distributed automation control systems in chemical and papermaking process industries.
