Allen-Bradley 6181P-12A2MW71DC DCS Industrial Computer

• Brand
  Allen-Bradley
• Model
  6181P-12A2MW71DC
• Product Name
  12.1-inch Integrated Display Industrial Computer
• Country of Origin
  USA
• HS Code
  8471504000
• Dimensions
  322mm×248mm×65mm
• Weight
  3.2kg
• Operating Temperature
  -20°C to +70°C
• Storage Temperature
  -40°C to +85°C
• Power Supply
  18V DC to 32V DC
• Warranty
  12 month
• Product Status
  New and original

Allen-Bradley 6181P-12A2MW71DC Product Introduction and Technical Parameters
Electrical Technical Parameters

Input Parameters: Adopts DC wide-voltage power supply input, with a rated input voltage range of 18V DC to 32V DC, adapting to industrial on-site DC power distribution systems. It is equipped with multiple standard industrial I/O interfaces, including USB ports, Ethernet ports, serial communication ports and audio interfaces, supporting multi-channel peripheral signal input and data transmission. The built-in DDR3 SODIMM memory module ensures stable data reading and writing during long-term operation, with strong compatibility with industrial peripheral equipment.

Output Parameters: It supports high-definition display output for real-time presentation of industrial monitoring screens, parameter data and operation interfaces. The analog resistive touch screen achieves high-precision touch response output, supporting accurate manual operation and parameter setting. It stably outputs network communication signals and serial data signals to realize data interaction, equipment linkage and remote transmission between on-site equipment and upper computer systems, with continuous and stable signal output and low delay.

Environmental Adaptation Parameters

Environmental Adaptability: Compliant with industrial electromagnetic compatibility standards, with excellent anti-electromagnetic interference, anti-vibration and dustproof capabilities. The sealed aluminum alloy structure prevents dust and moisture from invading internal components, and can resist electromagnetic interference and mechanical vibration generated by on-site motors, frequency converters and other equipment, suitable for complex and harsh industrial environments.

Core Product Characteristics

This industrial computer features an integrated all-in-one design that combines display, touch operation and industrial host, eliminating the need for separate host and display equipment and simplifying on-site wiring and installation. It adopts industrial-grade solid-state storage with no mechanical moving parts, greatly improving shock and vibration resistance compared with traditional mechanical hard drives. The wide-voltage DC power supply design avoids equipment shutdown failures caused by on-site voltage fluctuation. The industrial aluminum alloy frame ensures heat dissipation efficiency and structural durability. It supports stable operation of the Windows 7 Professional SP1 system and is compatible with most mainstream industrial configuration software, monitoring software and automation control systems. In addition, it has passed multiple international industrial certifications, with stable performance and strong environmental tolerance.

Main Functions

It realizes real-time on-site data monitoring, equipment operation status display and parameter adjustment, supporting intuitive human-machine interaction for industrial production lines. It completes on-site production data collection, recording and storage, facilitating production data statistics, traceability and analysis. It supports network and serial communication to realize data linkage with PLC, DCS and other automation control equipment, as well as remote data transmission and equipment monitoring. It operates stably with industrial control software to complete process parameter configuration, program debugging and production process monitoring. Meanwhile, it has system self-detection and fault prompt functions, which can timely feed back equipment operation abnormalities to ensure the continuity of industrial production.

Product Advantages

Firstly, the integrated all-in-one structure saves installation space and reduces on-site wiring costs and equipment failure points. Secondly, industrial-grade wide temperature design and solid-state storage configuration enable it to adapt to harsh industrial environments that ordinary commercial computers cannot withstand, with ultra-high operational stability. Thirdly, the mature Intel industrial processor and stable Windows operating system ensure good software compatibility, adapting to most traditional industrial automation systems. Fourthly, the DC wide-voltage input design has strong anti-fluctuation ability, effectively adapting to unstable power supply conditions on industrial sites. Finally, although the product has been discontinued, Rockwell Automation provides complete after-sales repair and technical support services, with long service life and high operational cost performance, and is very suitable for the maintenance and upgrading of existing old industrial automation systems.

Application Scenarios

This product is widely applied in industrial automation production and process control scenarios, including factory assembly lines, automated production workshops, intelligent manufacturing equipment monitoring and other discrete manufacturing fields. It is applicable to process control monitoring in chemical, petroleum, metallurgical, food and pharmaceutical industries, supporting real-time monitoring and parameter adjustment of continuous production processes. It can be used for on-site data acquisition and equipment operation control of building automation, logistics conveying equipment and environmental monitoring systems. In addition, it is suitable for the transformation, upgrading and spare part replacement of old Rockwell automation control systems, providing stable human-machine interaction and data processing support for various industrial on-site control systems.

Hardware Configuration Parameters

Processor: Equipped with Intel i3-4102E dual-core industrial processor, with a main frequency of 1.6GHz, meeting the operation requirements of industrial monitoring software, data logging and simple process control programs

Storage: Built-in 256GB MLC 2.5-inch solid-state drive (SSD), featuring fast read-write speed, shock resistance and low failure rate, effectively avoiding data loss caused by industrial vibration

Display & Touch: 12.1-inch industrial LCD display with 4:3 aluminum alloy bezel, matched with industrial analog resistive touch screen, supporting stable operation in dusty and humid industrial environments
