1900/65A-0001-01-00-00 Bently Nevada General Purpose Equipment Monitor

• Brand
• Model
• Product Name
• Country of Origin
• HS Code
• Dimensions
• Weight
• Operating Temperature
• Storage Temperature
• Power Supply
• Warranty
  12 month
• Product Status
  New and original

Bently Nevada 1900/65A-0001-01-00-00 General Purpose Equipment Monitor

Technical Parameters

Input

1. Vibration Input: 4 channels, compatible with proximity probes, accelerometers, velocity sensors

2. Temperature Input: 4 channels, supports Type E/J/K/T thermocouples, 2-wire/3-wire RTD sensors

3. Frequency Range: Vibration 1 Hz–25 kHz (configurable high-pass/low-pass filters)

4. Measurement Accuracy: ±1% full scale

5. Sampling Rate: High-speed real-time sampling, 24-bit ADC conversion

Output

1. Analog Output: 4-channel configurable 4–20 mA signal for recorder/DCS connection

2. Relay Output: 6 programmable relays (5A@250VAC/30VDC), independent Alert/Danger alarm control

3. Buffered Output: Diagnostic buffered signal for each transducer channel

4. Communication: RS-485 Modbus protocol, compatible with PLC/SCADA/DCS systems

Power Supply

1. Input Voltage: 18–36 VDC (corresponding to the "00" power option in the order number)

2. Power Consumption: ≤5 W

3.Operating Temperature: -20 ℃ ~ +65 ℃

4. Protection Grade: IP20 (standard)

5.Mounting Method: DIN rail mount or panel mount

Characteristics

1. Compact integrated structure, small footprint, easy installation and retrofit

2. Industrial anti-interference performance, stable operation in high-vibration, dusty and humid environments

3. Independent dual-threshold alarm (Alert & Danger) with adjustable delay to avoid false alarms from transient interference

4. Built-in self-diagnosis function, real-time sensor status monitoring and fault warning

5. 200-entry event log for equipment failure traceability and predictive maintenance analysis

6. Configurable measurement range, filter parameters and alarm thresholds via software

Functions

1. Real-time continuous monitoring of vibration displacement, velocity, acceleration and equipment temperature

2. Early detection of mechanical faults: bearing wear, rotor imbalance, shaft misalignment, loose parts, abnormal temperature rise

3. Two-level alarm and interlock protection to trigger shutdown or warning when equipment operates abnormally

4. Data transmission to upper industrial control systems via analog signal or digital Modbus communication

5. On-site status display via LED indicators and attached display screen

Product Advantages

1. Cost-effective monitoring solution, lower investment compared with high-end 3500 series monitors, suitable for balance-of-plant equipment

2. Wide compatibility with mainstream industrial sensors, no need for additional signal conversion modules

3. Flexible configuration, adapts to various types of auxiliary machinery monitoring scenarios

4. High reliability and long service life, proven performance in global industrial applications

5. Simple maintenance, plug-and-play structure, convenient module replacement and debugging

Application Cases

1. Power Industry: Monitoring of cooling tower fans, circulating water pumps, induced draft fans and small auxiliary turbines in thermal power plants

2. Oil & Gas Industry: Vibration protection of small compressors, transfer pumps and agitators in oil refineries and natural gas stations

3. Manufacturing Industry: Monitoring of fans, blowers, gearboxes and centrifuges in chemical, cement, paper-making and mining plants

4. Water Treatment Industry: Condition monitoring of water pumps and aeration equipment in sewage treatment plants

5. General Machinery: Protection of motors, small reciprocating compressors and other general-purpose rotating equipment

•
  1900/65A-0001-01-00-00 datasheet
