3500/62 163179-03 Bently Nevada monitor module new

• Brand
  Bently Nevada
• Model
  163179-03
• Product Name
  6-Channel Process Variable Monitor
• Country of Origin
  United States
• HS Code
  85437099
• Dimensions
  226mm×220mm×30mm (L×W×H)
• Weight
  0.8kg
• Operating Temperature
  0°C to +60°C
• Storage Temperature
  -40°C to +85°C
• Power Supply
  -10V DC to +10V DC
• Warranty
  12 month
• Product Status
  New and original

Bently Nevada 163179-03 3500/62 Product Overview

Electrical Specifications

1.Power Supply: 24V DC (±10% tolerance)

2.Power Consumption: 7.0 W (max)

3.Input: 6 analog input channels; supports 4–20 mA current signals and -10 VDC to +10 VDC voltage signals

4.Output: 2 relay outputs (for alarm/protection); digital communication outputs (Ethernet/RS-485)

5.Accuracy: ±0.02% full-scale (typical)

6.Response Time: <1 second

7.Operating Temperature: -30°C to +65°C

8.Protection Rating: IP20 (panel mount)

Core Product Characteristics

First, it adopts multi-channel independent monitoring design, with 6 channels working independently without mutual interference, which can simultaneously monitor multiple process variables of equipment. Second, it has ultra-high measurement accuracy and stable signal processing capability, which can eliminate industrial electromagnetic interference and ensure long-term stable data acquisition. Third, it has powerful on-board diagnostic functions, which can automatically detect sensor disconnection, signal overload, module operation failure and other faults, and feed back fault information in real time. Fourth, it supports flexible parameter configuration, and users can independently set measurement range, alarm threshold and filtering parameters according to on-site working conditions. Fifth, it is compatible with the full range of 3500 series rack systems, with plug-and-play installation and strong system compatibility. Sixth, it supports TMR redundant configuration, which can meet the safety monitoring requirements of high-reliability and high-risk industrial scenarios. In addition, the module has passed CE, UL, CSA and other international industrial safety certifications, with standard industrial protection level and rugged hardware structure.

Main Functions

This module mainly undertakes real-time acquisition, conditioning, analysis and alarm monitoring of industrial process variables. It continuously collects analog signals such as equipment operating pressure, medium flow, equipment temperature and liquid level in the production process, and converts and optimizes the original signals to form accurate and effective monitoring data. It compares the real-time collected data with the user preset alarm thresholds, and automatically triggers alert or danger alarm prompts when the parameters exceed the normal range, so as to remind operators to deal with abnormal equipment conditions in a timely manner. At the same time, it realizes real-time upload and storage of monitoring data, provides data support for equipment operation trend analysis, regular maintenance and fault tracing. It also completes self-diagnosis of the module and peripheral sensors, ensuring the integrity and reliability of the entire monitoring system, and realizing full-cycle safety monitoring and early warning for industrial rotating machinery and process equipment.

 Product Advantages

In terms of performance, the module has industry-leading ±0.1% full-scale accuracy and excellent anti-interference ability, which can maintain stable monitoring performance in high-temperature, high-vibration and strong electromagnetic interference industrial environments for a long time. In terms of safety, it supports intrinsically safe access and TMR redundant configuration, effectively avoiding monitoring blind spots and equipment safety accidents, and meeting the safety integrity requirements of industrial process control systems. In terms of compatibility, it is fully compatible with Bently Nevada 3500 series rack systems and mainstream industrial DCS systems, with simple installation and convenient system expansion and upgrade. In terms of operability, it supports independent configuration of each channel parameter, flexible adaptation to different equipment monitoring needs, and reduces on-site configuration and maintenance costs. In terms of reliability, it has built-in comprehensive fault diagnosis function, which can quickly locate faults, shorten equipment downtime, and improve the overall operational efficiency of the production system. In addition, it has long service life and stable operation, reducing the frequency of module replacement and later operation and maintenance costs for enterprises.

Application Cases & Scenarios

Power Generation Industry: Widely used in thermal power plant steam turbine, generator and auxiliary equipment monitoring. It monitors the bearing pressure, cooling water flow, operating temperature and other process parameters of large turbo-generator sets, realizes early warning of equipment overheating, pressure abnormality and flow failure, and ensures the safe and stable operation of power generation units.

Petrochemical Industry: Applied to condition monitoring of rotating equipment such as compressors, pumps and reactors in oil and gas exploitation, refining and chemical production plants. It tracks key process variables such as equipment operating pressure, medium flow and tank liquid level in hazardous production areas, and supports intrinsically safe monitoring to avoid production safety risks caused by abnormal equipment parameters.

Heavy Industry & Manufacturing: Used for monitoring large industrial fans, blowers and reciprocating machinery in metallurgy, mining and cement industries. It monitors the operating state of core production equipment in real time, predicts potential mechanical faults through parameter trend changes, and provides basis for predictive maintenance of equipment.

Industrial Process Control System: As an important signal acquisition and monitoring unit of industrial TSI systems, it is matched with 3500 series systems to build a complete equipment condition monitoring system, which is widely used in various industrial scenarios that require high-precision and high-reliability process variable monitoring and machinery protection.

Key Features

1.Multi-Channel Monitoring: 6 independent analog input channels for simultaneous monitoring of multiple process variables.

2.High Precision & Stability: Ultra-high accuracy (±0.02% F.S.) and wide temperature tolerance for harsh industrial environments.

3.Flexible Signal Compatibility: Accepts both 4–20 mA current and ±10 VDC voltage inputs for seamless integration with standard sensors.

4.Integrated Alarm Management: Configurable threshold alarms (warning/danger) with relay outputs for direct protection interlocks.

5.Robust Communication: Supports Ethernet and RS-485 (Modbus RTU) for data transmission to DCS, PLC, or SCADA systems.

6.Compact & Modular Design: Standard 19-inch rack-mount form factor for easy installation and hot-swap replacement in the 3500 system.

•
  3500/62 163179-03 datasheet
  Download
