H927046C0700 Foxboro DCS Interface Module

• Brand
  Foxboro
• Model
  H927046C0700
• Product Name
  Interface Module
• Country of Origin
  United States
• HS Code
  8537109090
• Dimensions
  245 mm(H)×190 mm(W)×40 mm(D)
• Weight
  1.15 kg
• Operating Temperature
  -30℃ to +60℃
• Storage Temperature
  -25℃ to +75℃
• Power Supply
  24 VDC ±10%
• Warranty
  12 month
• Product Status
  New and original

Input Interfaces

1.USB: Multiple USB 2.0/3.0 ports for mouse, keyboard, touchscreen, annunciator keyboards, and external peripherals

2.Ethernet: Integrated 10/100/1000BaseT Ethernet ports (expandable to 3 NICs)

3.Video: Quad mini-DP 1.4 ports supporting up to 4 Full HD (1920×1080) monitors

4.Optional: GPS time synchronization card, USB touchscreen support

Output Interfaces

1.Display Output: Up to 4 independent video outputs for multi-monitor HMI setups

2.Ethernet: Data communication output to DCS control networks

3.Audio: Optional external speaker output

Functions

1.Host Foxboro DCS control stations

2.Serve as HMI workstation for process monitoring and operation

3.Support data communication with field I/O devices

4..Act as application server for Foxboro, third-party, and custom software

5.Execute control algorithms, data processing, and real-time diagnostics

6.Enable Ethernet-based network control and system integration

Application Cases

1.Petrochemical Industry: Process monitoring and control for refineries, reactor control, and pipeline automation

2.Power Generation: Boiler control, turbine monitoring, and power plant DCS operation

3.Metallurgy: Blast furnace control, hot rolling mill process regulation

4.Water Treatment: Flow control, valve regulation, and water purification system management

5.Pharmaceutical & Chemical: Sterile process control, precise parameter regulation for chemical reactions

Product Advantages

1.High Reliability: Industrial-grade hardware with ECC memory and RAID support minimizes downtime

2.Strong Compatibility: Seamless integration with Foxboro I/A Series and third-party DCS systems

3.Powerful Performance: High-performance computing for complex control and data processing tasks

4.Flexible Configuration: Expandable memory, storage, and interfaces to meet diverse project needs

5.Stable Operation: Wide temperature tolerance and rugged design for harsh industrial environments

6.User-Friendly HMI: Multi-monitor support and intuitive interface for efficient operation

7.Schneider Electric Support: Backed by global technical service and long-term product availability

Features

1.Powered by Intel Xeon high-performance processor

2..8GB DDR4 ECC registered RAM (expandable to 16GB)

3.1TB SATA hard drive (expandable to 3TB with 3 drives; supports RAID1)

4.Built-in DVD+RW/CD drive

5.PCIe x16 graphics slot with multi-display support

6.Compatible with Windows 10 21H2 LTSC and Windows 7 64-bit operating systems

7.Supports Foxboro DCS software licensing and control core services

8.Robust industrial-grade construction for harsh environments

9.Redundancy-capable configuration for system reliability
