DS200TCCAG1BAA GE DCS Analog I/O Board

• Brand
  GE
• Model
  DS200TCCAG1BAA
• Product Name
  TC2000 Analog I/O Board
• Place of Origin
  United States
• HS Code
  85389091
• Dimensions
  260 mm × 165 mm × 30 mm
• Weight
  0.54 kg
• Operating Temperature
  -20°C ~ +60°C
• Storage Temperature
  -40°C ~ +85°C
• Power Supply
  24VDC
• Warranty
  12 month
• Product Status
  New brand

Backed by abundant in-stock inventory and nearly 20 years of industry experience, our company stands as a leading player in the industrial control sector.We offer an extensive range of industrial control products covering numerous models. Should you have any other requirements, please feel free to contact us, and we will respond to you promptly.

Our main brand:

1.ABB's module cards, touch screens, controllers, etc., such as PP846 touch screen, IGCT starting with 5SHY, PM starting controller, AI, DO starting input/output module, SP starting Bailey module, etc

2.GE's module card CPUs, such as VMIC starter, IS200, IS215, IS400, IS420 series, etc,

3.Emerson's card components and EPRO probes, Westinghouse 1C series, Honeywell CC series, Schneider 140 series, Envision full series, Bentley 3500 series, Rexroth motors and drives, and Foxboro small modules.

Model: DS200TCCAG1BAA

Series: GE Speedtronic Mark V TC2000 Common Analog I/O Board

Power Supply for Board Backplane:+5 VDC ±5%

Max supply current: 6 A

Typical power consumption: 12 W

Analog Signal Input Ranges:

±10 VDC voltage input;

0–10 VDC voltage input;

4–20 mA current input;

Thermocouple inputs;

RTD resistance inputs

Input impedance: > 1 MΩ

Analog Signal Output Ranges:

±10 VDC voltage output;

4–20 mA current output

Analog Output Channel Drive Capacity:

Voltage output: Low current drive, maximum 5 mA per channel

Current output: 4–20 mA standard loop signal

Analog Input Operation

This board supports a wide range of common industrial analog input signals, including ±10 VDC, 0–10 VDC voltage signals, 4–20 mA current signals, as well as RTD and thermocouple measurement signals. Its internal hardware circuits perform a series of preprocessing operations on incoming signals, including filtering, noise suppression and amplification. Specifically, thermocouple input channels are equipped with cold junction compensation capability to eliminate temperature measurement errors, while RTD channels adopt constant current excitation circuits to convert resistance changes caused by temperature variations into accurate voltage signals. All conditioned analog signals are converted into 12-bit digital data via the integrated ADC module, and subsequently transmitted to the system I/O engine through the backplane 3PL interface for further control algorithm computation.

Analog Output Operation

Upon receiving digital control instructions from the system I/O engine, the on-board microprocessor analyzes and processes the data, then drives the built-in DAC module to output standard industrial analog signals, covering ±10 VDC voltage signals and 4–20 mA loop current signals. These output signals are deployed to control field equipment such as actuators, regulating valves and on-site display indicators, realizing real-time adjustment of turbine operating parameters.

Overall Operational Mechanism

During full-time system operation, the board continuously completes high-precision signal sampling, data calibration and scaling, and real-time self-fault diagnosis. The integrated status LED intuitively reflects the board’s operating state and fault information. By acquiring real-time process feedback signals and outputting corresponding regulation commands, the board enables stable and reliable closed-loop feedback control for gas and steam turbine units.
