IS200VAICH1D GE DCS VME Analog Input Board

• Brand
  GE
• Model
  IS200VAICH1D
• Product Name
  VME Analog Input Board
• Place of Origin
  United States
• HS Code
  8537101190
• Dimensions
  233 mm × 160 mm × 25 mm
• Weight
  0.48 kg
• Operating Temperature
  -30 °C to +65 °C
• Storage Temperature
  -40 °C to +85 °C
• Power Supply
  0–20 mA and 4–20 mA
• Warranty
  12 month
• Product Status
  New and original

Backed by abundant in-stock inventory and nearly 20 years of industry experience, our company stands as a leading player in the industrial control sector.We offer an extensive range of industrial control products covering numerous models. Should you have any other requirements, please feel free to contact us, and we will respond to you promptly.

Our main brand:

1.ABB's module cards, touch screens, controllers, etc., such as PP846 touch screen, IGCT starting with 5SHY, PM starting controller, AI, DO starting input/output module, SP starting Bailey module, etc

2.GE's module card CPUs, such as VMIC starter, IS200, IS215, IS400, IS420 series, etc,

3.Emerson's card components and EPRO probes, Westinghouse 1C series, Honeywell CC series, Schneider 140 series, Envision full series, Bentley 3500 series, Rexroth motors and drives, and Foxboro small modules.

Analog Inputs (AI):

Equipped with 20 channels of analog field input interfaces. Input signal types can be flexibly configured through jumpers on the matched terminal board. Supported signal ranges include 4–20 mA and ±1 mA; certain hardware variants are also compatible with ±5 V and ±10 V voltage input signals. The board adopts 16-bit high-precision ADC conversion, built with open-circuit fault detection function, integrated signal conditioning circuit and electrical isolation protection to effectively suppress field interference and improve signal acquisition stability.

Analog Outputs (AO):

Features 4 channels of analog field output. Channel 1 and Channel 2 support mode selection via on-board jumpers, available for 4–20 mA or 0–200 mA output modes. Channel 3 and Channel 4 are fixed to 4–20 mA current output. Signals are generated via digital-to-analog conversion (DAC). This module supports TMR redundant voting architecture, which is designed for high-reliability turbine control systems to meet strict safety and continuous operation requirements.

Backplane Communication:

Implements digital data interaction with the main controller via VME backplane bus. This internal communication channel is used for command transmission and process data exchange between the I/O board and controller, and does not provide external field wiring terminals.

Environmental Inspection

Perform periodic inspections of the control cabinet’s temperature, humidity and dust levels. Maintain operating temperature within official specifications. Prevent heavy dust buildup, corrosive vapor and condensation from forming on the module surface. Confirm cabinet cooling fans operate properly to eliminate risks of module overheating.

Module Visual Inspection

Carry out visual checks on the printed circuit board for burn marks, corrosion, swollen capacitors and detached components. Ensure no debris collects on the PCB and connectors. Watch out for traces of water ingress or chemical contamination.

Connector and Wiring Maintenance

Inspect the VME backplane connector and field wiring terminals. Ensure all connectors are fully inserted and securely locked. Check for loose terminals, oxidized pins, damaged cables and intermittent contact. When power is disconnected, clean corroded pins using industry-approved contact cleaner.

Signal Circuit Inspection

Monitor analog input and output signals while the system is running. Confirm AI/AO readings are consistent with connected field instruments. Periodically verify the open-circuit detection capability of analog inputs. Check signal integrity to rule out significant drift or electrical noise interference.

Power Supply Monitoring

Monitor the module’s operating voltage through the control system. Voltage fluctuations can lead to inaccurate signal sampling or module faults. Ensure no excessive voltage drop exists across power terminals.

System Functional Testing

Regularly test module communication via the Mark VI controller to ensure reliable data transfer over the VME bus. Follow scheduled maintenance procedures to calibrate analog input and output channels, sustaining consistent measurement precision.

ESD Protection Guidelines

All maintenance activities must comply with electrostatic discharge standards. Put on an anti-static wristband prior to handling the circuit board. Shut down power to the corresponding rack before mounting or removing the module to prevent permanent hardware damage.

Spare Module Management

Preserve spare IS200VAICH1D units inside anti-static packaging in a dry, temperature-stable storage location. Avoid prolonged exposure to severe industrial conditions. Where feasible, implement regular testing rotation for spare modules.
