ICS Triplex T8110B DCS processor module

• Brand
  ICS Triplex
• Model
  T8110B
• Product Name
  Trusted TMR Safety Processor Module
• Country of Origin
  United States
• HS Code
  85371011
• Dimensions
  266mm× 93mm×303mm
• Weight
  2.94kg
• Operating Temperature
  0°C to +60°C
• Storage Temperature
  -25°C to +70°C
• Power Supply
  24 VDC
• Warranty
  12 month
• Product Status
  New and original

ICS Triplex T8110B Product Introduction and Technical Parameters

Electrical Parameters

The T8110B supports dual redundant industrial DC power supply for high-reliability power input, with a wide adaptive voltage range of 10VDC to 32VDC and a rated operating voltage of 24VDC. It features low standby power consumption of 1W and a maximum operating power of 80W under full load conditions. The built-in high-stability power regulation circuit ensures constant voltage and current output, resisting on-site power fluctuation and surge interference. Integrated over-voltage, under-voltage and over-current protection functions effectively avoid module burnout and system crash caused by power supply anomalies. The whole machine adopts isolated power design to enhance electrical safety and system anti-interference capability.

Core Product Characteristics

Firstly, it features professional TMR fault-tolerant architecture. The triple modular redundant design and 2oo3 voting logic completely avoid single-point faults, ensuring ultra-high operational reliability for safety-critical systems.

Secondly, it supports long-term data retention and complete event recording. The non-volatile storage technology ensures no loss of key data during power failure, and high-capacity SOE buffer realizes comprehensive system event traceability.

Thirdly, it adopts dual redundant power supply design. The dual-power input mechanism improves power supply stability and avoids system shutdown caused by single power supply failure.

Fourthly, it integrates multi-port communication and safety protection functions. Rich configurable communication interfaces meet diverse system docking requirements, and physical keyswitch protection prevents unauthorized parameter modification to ensure system operation safety.

Product Advantages

The ICS Triplex T8110B possesses prominent comprehensive advantages as a core safety processor module. Its SIL3-certified safety performance fully complies with international industrial safety standards, effectively reducing operational risks of high-risk production systems. The TMR fault-tolerant design ensures continuous and stable system operation without interruption even under single-module faults, greatly improving production safety and system redundancy. The integrated multi-communication ports and powerful data processing capabilities simplify system architecture and improve overall operational efficiency. With reliable environmental adaptability, perfect power protection and intelligent data retention functions, it adapts to complex industrial working conditions. Verified by long-term field applications, it features stable performance and convenient maintenance, serving as the preferred core control processor for industrial SIS safety instrumented systems.

Interface and Functional Configuration

As the core CPU module of the Trusted system, the T8110B is equipped with a triple redundant Inter-Module Bus (IMB) to realize high-speed data interaction with all system I/O modules. It configures one front-panel RS232 diagnostic port and two configurable RS422/485 serial communication ports for system debugging, parameter configuration and upper computer data transmission. The module supports up to 1000 local SOE event buffer records, which can be expanded to 4000 events through the system CI buffer, achieving millisecond-level accurate event timestamp recording. It integrates independent system mode keyswitch to prevent unauthorized operation, and supports 10-year non-volatile data retention to preserve system programs, fault logs and configuration data during power failure.
