S712-02-NANANA Kollmorgen DCS servo drive

• Brand
  Kollmorgen
• Model
  S712-02-NANANA
• Product Name
  S700 Series Single-axis Digital Servo Drive
• Country of Origin
  Germany
• HS Code
  8504409090
• Dimensions
  125mm(H)×415mm(W)×350mm(D)
• Weight
  4.4kg
• Operating Temperature
  -15℃ to +100℃
• Storage Temperature
  -35℃ to +120℃
• Power Supply
  24VDC
• Warranty
  12 month
• Product Status
  New and original

Kollmorgen S712-02-NANANA Product Specification Document

Input Specifications

1.Main Power Input: 3-phase AC 208~480V, 50/60Hz (188~528V wide voltage tolerance)

2.Control Power Supply: 24VDC

3.Analog Input: 2-channel programmable 0~10VDC analog input

4.Digital Input: 4-channel programmable 24VDC digital input

5.Communication Input: EtherCAT, CANopen onboard bus interface; RS232 debugging port

6.Feedback Input: Support EnDat 2.1/2.2, SinCos HIPERFACE, incremental encoder, Hall sensor feedback

Output Specifications

1.Rated Output Current: 12A RMS continuous

2.Rated Line Power: 9kVA

3.Max DC Bus Voltage: 900VDC

4.Digital Output: 2-channel programmable 24VDC digital I/O

5.Control Output: PWM three-phase power output for servo motor driving

Main Functions

1. Multi-mode motion control: Torque control, speed control, position control, electronic gear function

2.Closed-loop high-precision regulation: Fast dynamic response to restrain motor speed fluctuation

3.Built-in motion programming: Support IEC61131 macro programming for independent axis motion execution

4.STO safety protection: Cut motor torque output instantly under emergency condition for mechanical safety

5. Multi-feedback compatibility: Match mainstream encoder feedback signals for full closed-loop positioning

6.Parameter backup & copy: Support MMC memory card for firmware and parameter duplication

7. Auto-tuning function: Automatic motor parameter identification to simplify commissioning

8. Fault self-diagnosis: Real-time fault alarm and code feedback for quick troubleshooting

Product Advantages

1.Ultra-fast dynamic response: High-frequency loop control improves machine cycle efficiency and machining precision

2.Complete bus configuration: Onboard EtherCAT/CANopen without extra expansion card, convenient system integration

3.Wide motor compatibility: Drive synchronous, asynchronous, linear and DC servo motors flexibly

4.Integrated design: Built-in filter and braking resistor, reduce peripheral components and cabinet space occupation

5. High safety standard: Standard STO safety function lowers equipment accident risk

6.Low maintenance cost: Stable digital hardware structure, long service life, convenient parameter copying for batch commissioning

7.Global voltage adaption: Wide input voltage range fits European, Asian and American industrial power grids

Application Cases

1.Packaging Machinery: Multi-axis positioning control for filling, sealing and carton packaging equipment

2.Printing & Converting Industry: High-precision tension control and register positioning for printing slitting machines

3.Automated Machine Tools: Feed axis servo driving for CNC cutting, drilling and milling equipment

4. Material Handling: Robotic joint motion control, palletizing and conveying positioning system

5.Textile Machinery: Spinning, weaving and winding high-speed constant-tension driving

6.Medical Automation: Precision positioning control for medical processing and inspection equipment

7. Lithium Battery Equipment: Winding, slitting and stacking high-speed servo positioning control

Core Characteristics

1. Operating Temperature: 0℃~+45℃ continuous operation; storage temperature -25℃~+55℃

2. Protection Grade: IP20, indoor cabinet installation

3. Safety Certification: STO Safe-Torque-Off, PL d, SIL CL2 certification conforming to EN62061

4. Control Mode: Full digital current/speed/position triple closed-loop control

5. Shell Structure: Metal casing, integrated EMC filter and braking resistor inside

6. Anti-interference: CE, UL, TÜV certified, strong EMC anti-interference capability

7. Noise Level: ≤58dB(A) during operation
