8JSA44.E6040D100-0 DCS servo motor NEW AND ORIGINAL

• Brand
  B&&R
• Model
  8JSA44.E6040D100-0
• Product Name
  High-Precision Synchronous Servo Motor
• Country of Origin
  Austria
• HS Code
  8501510000
• Dimensions
  185mm×115mm×115mm
• Weight
  4.8kg
• Operating Temperature
  -20°C to +40°C
• Storage Temperature
  -30°C to +80°C
• Power Supply
  24VDC
• Warranty
  12 month
• Product Status
  New and original

B&R 8JSA44.E6040D100-0 Product Introduction and Technical Specifications

Input Technical Parameters

Power Supply Input: Matches B&R dedicated servo drive three-phase AC power supply input, supporting standard industrial AC voltage input. It can withstand short-term voltage fluctuation and transient power surge interference, adapting to complex industrial power supply conditions and ensuring stable power input for motor operation.

Control Signal Input: Supports differential pulse signal and serial bus control signal input, compatible with mainstream industrial motion control signal protocols. It can receive high-precision position commands, speed commands and torque commands from the servo driver, with sensitive signal response and low delay, realizing accurate motion command execution.

Encoder Signal Input: Built-in high-resolution encoder signal receiving loop, supporting real-time sampling and feedback of motor rotation position and speed signals, providing accurate closed-loop control data for the servo system.

Output Technical Parameters

Mechanical Motion Output: Features rated stable speed output and low-speed high-torque performance, with smooth operation and no jitter. It realizes precise stepless speed regulation and fixed-position positioning, fully meeting the precision motion requirements of automated mechanical equipment.

Torque Output: Has strong instantaneous overload torque output capability, which can quickly respond to equipment load sudden changes, effectively solving the problem of insufficient power during equipment start-up and heavy-load operation, and improving equipment operation stability.

Encoder Feedback Output: Equipped with high-precision incremental encoder feedback output, which can real-time feed back motor operating speed, rotation angle and position information to the upper drive system, forming a high-precision closed-loop control system and ensuring motion control accuracy.

Status Signal Output: Supports motor operating status signal output, including over-temperature alarm, overload prompt and fault state feedback signals, facilitating real-time system monitoring and equipment fault diagnosis.

B&R 8JSA44.E6040D100-0 Product Core Advantages

High Precision Motion Control: Adopts high-resolution encoder and optimized magnetic circuit design, with extremely low speed fluctuation and positioning error. It realizes micron-level precise positioning and stable speed operation, fully meeting the ultra-high precision processing and motion control requirements of intelligent automation equipment.

Excellent Dynamic and Load Performance: Features high power density, fast dynamic response and strong overload capacity. It can complete rapid start-stop and frequent acceleration and deceleration actions, adapt to high-frequency cyclic operation of automated equipment, and effectively improve production efficiency.

Low Energy Consumption and High Stability: Optimized winding and rotor structure design effectively reduces motor operation loss and heat generation. The motor runs smoothly with low noise and low torque ripple, ensuring long-term uninterrupted stable operation and reducing equipment energy consumption and failure rate.

B&R 8JSA44.E6040D100-0 Wiring Method

The B&R 8JSA44.E6040D100-0 adopts standardized aviation plug integrated wiring design, divided into power wiring interface, encoder signal wiring interface and shielding grounding interface, with clear functional division and standardized on-site wiring procedures.

For power wiring, use a dedicated servo power cable to connect the motor power terminal plug to the corresponding power output terminal of the B&R servo driver. Ensure firm plug insertion and locking, strictly avoid poor contact caused by mechanical vibration, and guarantee stable three-phase power supply transmission.

For encoder signal wiring, connect the dedicated shielded encoder cable to the motor encoder interface and the driver signal interface respectively. Standard shielding and grounding treatment shall be implemented to isolate on-site electromagnetic interference and ensure accurate and stable signal transmission.

For grounding wiring, connect the motor grounding terminal to the equipment unified grounding system to eliminate static electricity and electromagnetic interference risks, and improve the safety and stability of the servo system operation. After completing all wiring, check the tightness of all interfaces and the correctness of the wiring sequence.

Finally, conduct power-on inspection, signal debugging and no-load trial operation. Verify the motor start-stop, speed regulation and positioning functions are normal, calibrate the system control parameters, and ensure the servo motor operates stably and accurately under load conditions.

•
