PSC500-400 ORGA DCS Power Supply Unit

• Brand
  ORGA
• Model
  PSC500-400
• Product Name
  Marine Hazardous Area Power Supply Unit
• Place of Origin
  Netherlands
• HS Code
  85044090
• Dimensions
  210mm (W) × 250mm (H) × 95mm (D)
• Weight
  2.2 kg
• Operating Temperature
  -30°C ~ +65°C
• Storage Temperature
  -40°C ~ +75°C
• Power Supply
  24VDC
• Warranty
  12 month
• Product Status
  New and orginal

ORGA PSC500-400 Introduction and Technical Specifications

Electrical Parameters

Operating Voltage: 115/230 VAC, 50/60Hz / 400Hz marine standard power supply

Rated Power: 400VA maximum continuous output power

Operating Current: 3.4A max input current @120VAC, 0.28A max input current @277VAC

Output Performance: Stable constant voltage output with built-in power filtering, compatible with ORGA marine navigation light series

Integrated protection functions including overvoltage, overcurrent, short circuit and over-temperature protection

Humidity: 0%–98% non-condensing marine humidity environment

Protection Grade: IP66 waterproof and dustproof rating

Environmental adaptability: Resists seawater corrosion, UV radiation, vibration and salt fog, certified for marine offshore and Zone 2 hazardous area operation

PSC500-400  ORGA Product Advantages

1. Professional marine explosion-proof and hazardous area certification, compliant with international offshore safety standards for Zone 2 flammable environments.

2. Wide-range AC voltage and frequency adaptation, perfectly matching ship and offshore platform special power grid parameters.

3. High-precision stable power output effectively avoids lighting flicker and equipment damage caused by marine power grid fluctuation.

4. IP66 fully enclosed rugged housing with salt fog and corrosion resistance, long service life in harsh marine environments.

5. Multiple built-in safety protection mechanisms realize automatic fault shutdown and overload protection, improving system operational safety.

6. Compact and lightweight structure with simple installation and wiring, reducing on-site construction and maintenance costs.

7. Exclusive compatibility with ORGA full-series marine navigation lights and auxiliary equipment, achieving seamless system matching and stable synchronous operation.

PSC500-400  ORGA  Application Scenarios

Mainly applied for power supply of marine navigation lighting systems, offshore platform safety lights, ship explosion-proof signal lights and offshore auxiliary electrical equipment. It is widely used in offshore wind farms, oil and gas platforms, cargo ships, engineering vessels and other marine industrial scenarios with hazardous area operation requirements.

PSC500-400  ORGA Wiring & Installation Method

Wiring Mode: Equipped with M25 cable gland ports, supports max 4mm² marine shielded cables for input and output wiring; features internal standard earth connection for safety grounding

Installation Method: Wall-mounted and cabinet fixed installation, matched with stainless steel anti-corrosion mounting brackets suitable for offshore platform and ship cabin installation

Standard terminal wiring design with clear power input and load output partitions, convenient for on-site wiring, inspection and maintenance

•
