3HAC055450-003 ABB servo motor instock

• Brand
  ABB
• Model
  3HAC055450-003
• Order No.
  3HAC055450-003
• Product Name
  AC Servo Motor
• Country of Origin
  Sweden
• Customs Tariff Number
  85015220
• Dimensions
  341 mm *178 mm*178 mm
• Weight
  29.81 kg
• operating temperature
  0°C to +40°C
• storage temperature
  -40°C to +70°C
• Warranty
  12 month
• Product Status
  new and original

ABB 3HAC055450-003 Product Brief Introduction
1.Power Supply Industrial three-phase AC power supply, rated 400 VAC, 50 Hz to 60 Hz frequency adaptation

2.Input Three-phase AC input voltage 380 V to 460 V, with wide voltage fluctuation resistance, matching robot drive unit output parameters

3.Output Rated power 2.27 kW, rated continuous torque 5 Nm, standard rated speed 3000 rpm, with 300% transient overload capability

Main Functions
Mainly used for driving robot joint axis movement, providing stable torque output and accurate speed adjustment. It feeds back real-time position and speed signals to the robot control system, realizes precise positioning and trajectory operation, and cooperates with other axis motors to complete multi-axis linkage, so as to meet the action requirements of complex handling, processing and assembly operations.

Practical Application Cases
Mainly supporting ABB IRB 6700 series robot axis drive, widely used in automotive manufacturing welding workshops, precision parts assembly production lines, industrial spraying processes, heavy material handling, metal processing and other heavy industrial fields. It maintains stable operating state under high frequency cyclic load and harsh working conditions, effectively improving the operating accuracy and production efficiency of automated equiment。

Core Features
Adopting low inertia rotor design to realize fast acceleration and deceleration response, IP54 overall protection level to prevent workshop dust and liquid splashing. Integrated high-resolution incremental encoder ensures accurate position feedback, natural air cooling structure reduces mechanical failure points. It owns outstanding low-speed operation stability, strong anti-vibration capability and long service life, and passes strict factory aging test and performance inspection.

•
