ABB 3HAC055440-003 AC servo motor

• Brand
  ABB
• Model
  3HAC055440-003
• Order No.
  3HAC055440-003
• Product Name
  Industrial Robot AC Servo Motor
• Country of Origin
  Sweden
• Customs Tariff Number
  85015220
• Dimensions
  328 mm(L)*170 mm(W)*170 mm(H)
• Weight
  25.8 kg
• operating temperature
  0°C to +40°C
• Storage temperature
  -40°C to +70°C
• Warranty
  12 month
• Product Status
  new and original

ABB 3HAC055440-003 Product Brief Introduction

1.Power Supply Matches industrial standard three-phase AC power supply system, rated working voltage of 400 VAC, and automatically adapts to 50 Hz and 60 Hz industrial power grid frequency

2.Input Three-phase AC input voltage range of 380 V to 460 V, with strong voltage fluctuation resistance, stable input current transmission, and good matching performance with ABB robot servo drive unit

3.Output Rated continuous output power reaches 2.8 kW, stable continuous output torque ensures smooth operation, rated working speed is 3000 rpm, with excellent high-speed operation performance and instantaneous overload capacity, meeting the dynamic load demand of robot high-frequency movement

3HAC055440-003 Main Functions
As the core power drive component of robot high-speed joint axis, 3HAC055440-003 provides stable power output, accurate speed regulation and balanced torque transmission during robot operation. 3HAC055440-003 collects real-time motor speed, angle and position data through the built-in encoder, and feeds back signals to the robot control system to realize closed-loop accurate control. It cooperates with the main controller and other axis drive motors to complete multi-axis linkage trajectory planning, precise repeated positioning, high-speed handling and flexible action switching, and provides reliable power guarantee for automated and intelligent operation of industrial robots.

3HAC055440-003 Practical Application Cases
3HAC055440-003 widely matched with ABB IRB 6700 series heavy-duty industrial robots, and applied to multiple heavy-duty automation industries including automobile manufacturing appearance spraying production lines, electronic components precision assembly workshops, general industrial high-speed material handling systems, packaging and palletizing automation equipment, and light metal processing and handling stations. 3HAC055440-003 can maintain long-term stable and efficient operation under high-frequency cyclic working conditions and complex electromagnetic interference environments, effectively improving production line operation efficiency, reducing failure rate, and ensuring the overall stability and safety of industrial automation equipment.

3HAC055440-003 Core Features
Compact and integrated overall structure, small installation size and flexible arrangement space.3HAC055440-003 adopts low-noise operation design and natural air cooling heat dissipation mode, without fan structure, reducing failure points and improving long-term operation stability. It reaches IP54 industrial protection grade, effectively preventing industrial dust accumulation and liquid splashing erosion. With low inertia rotor design, it achieves fast acceleration and deceleration response, strong anti-vibration, anti-interference and anti-fatigue capabilities. The built-in high-resolution incremental encoder guarantees high-precision position and speed feedback, and optional integrated mechanical brake structure provides safe locking protection for robot joints. All products have passed strict factory aging test and full-load performance inspection, with stable quality and long service life.

•
