Description
-
BrandABB
-
Model1HC0026292R0202
-
Product NameIndustrial Automation Control System Module
-
Place of OriginSwitzerland
-
HS Code85423190
-
Dimensions115mm × 95mm × 35mm
-
Weight0.38kg
-
Operating Temperature-25°C ~ +60°C
-
Storage Temperature-40°C ~ +85°C
-
Part Number1HC0026292R0202
-
Warranty12 month
-
Product StatusNew and original
ABB 1HC0026292R0202 Product Overview & Technical Specifications
Electrical Parameters
Rated Operating Voltage: 24VDC industrial safety extra-low voltage
Allowable Voltage Range: 19.2VDC ~ 30VDC
Typical Operating Current: 0.15A (full load operation)
Maximum Power Consumption: 3.6W
Built-in Protection: Reverse polarity protection, overcurrent protection and ESD anti-static protection
Working Humidity: 5% ~ 95%, non-condensing environment
Environmental Resistance: Complies with industrial EMC anti-interference standards, resists workshop vibration and electromagnetic radiation interference
1HC0026292R0202 ABB Core Product Advantages
Compact Design: Small size and light weight, saving cabinet installation space and optimizing layout.
Low Power Consumption: Low heat generation during operation, reducing cabinet heat load and extending service life.
Strong Stability: Industrial-grade circuit design, anti-vibration and anti-interference, adapting to harsh industrial working conditions.
High Compatibility: Perfectly compatible with matched ABB automation control systems, convenient for system integration and upgrade.
Easy Maintenance: Standard DIN rail installation, plug-and-play replacement, reducing on-site maintenance time and cost.
Long Service Life: High-quality original electronic components, supporting long-term uninterrupted industrial operation.
1HC0026292R0202 ABB Standard Wiring Method
Pre-wiring Preparation
Completely cut off the cabinet power supply before wiring to avoid electric shock and module burnout.
Power Wiring
Connect 24VDC positive and negative cables to the dedicated power terminals of the module, fasten the terminals firmly, and connect the grounding wire to the module grounding terminal to enhance anti-interference performance.
Signal Wiring
Adopt shielded twisted-pair cables for all input and output signal lines. Wire strictly according to terminal definitions, distinguish analog and digital signal interfaces, and avoid wrong connection.
Installation & Post-wiring Check
Fix the module on standard DIN rail, separate signal cables from high-power AC cables to prevent interference. After wiring, check all terminals for looseness, power on and verify module running status and signal communication validity.
