COM0002 2RAA005844A0005H 2RAA005697M ABB DCS module

• Brand
  ABB
• Model
  COM0002
• Product Name
  Industrial DCS/PLC Communication Expansion Module
• Country of Origin
  Sweden
• HS Code
  85423190
• Dimensions
  120mm × 100mm × 50mm
• Weight
  0.48kg
• Operating Temperature
  -20°C to +60°C
• Storage Temperature
  -40°C to +85°C
• Part Number
  2RAA005844A0005H 2RAA005697M
• Warranty
  12 month
• Product Status
  New and original

ABB COM0002 2RAA005844A0005H 2RAA005697M Product Overview & Technical Specifications

 Electrical Parameters

Rated supply voltage: 24VDC

Allowable voltage range: 19.2VDC ~ 30VDC

Typical operating current: 0.22A (full load)

Max power consumption: 5.5W

Built-in protections: Reverse polarity protection, self-recovery overcurrent protection and 2kV ESD electrostatic protection for signal ports

Applicable humidity: 5% ~ 95% non-condensing

Vibration resistance: Compliant with IEC 60068-2-6 industrial standard

Applicable altitude: Stable operation below 2000m

COM0002 2RAA005844A0005H 2RAA005697M ABB  Product Advantages

It adopts a split modular structure of main module and terminal base, enabling convenient single-board replacement without re-wiring, which reduces maintenance time and cost. The module integrates multiple common industrial protocols including Modbus TCP/RTU and Profibus DP, with strong compatibility for mainstream automation equipment. It features low power consumption and low heat generation, optimizing cabinet operating environment. With a wide temperature working range and excellent EMC anti-interference capability, it adapts to complex industrial site conditions. Plug-and-play rack installation improves on-site commissioning and renovation efficiency. Equipped with a hardware watchdog circuit, it automatically resets abnormal communication channels to ensure stable system operation. In addition, it has reliable component quality and complete global safety certifications, supporting long-term uninterrupted industrial operation and export equipment application.

COM0002 2RAA005844A0005H 2RAA005697M ABB Core Interface & Performance Parameters

Interfaces: 10/100Mbps Ethernet port, RS485 serial port, Profibus DP expansion interface, internal high-speed backplane bus

Processor: Industrial 32-bit RISC dedicated communication chip

Storage: 4MB Flash for firmware, 512KB RAM for real-time data cache

Indicator lights: Power, running, fault and bus status indicators for real-time operating status monitoring

COM0002 2RAA005844A0005H 2RAA005697M ABB  Wiring Method

All power and signal wiring is implemented on the supporting 2RAA005697M terminal base. For power wiring, cut off the system power in advance, connect 24VDC positive and negative wires to the dedicated power terminals, fasten the terminals with standard torque and connect the grounding wire to the grounding pin for anti-interference protection. For communication wiring, use shielded industrial cables for Ethernet, RS485 and fieldbus interfaces. Match A/B signal lines strictly according to interface definitions, install 120Ω terminal resistance at both ends of the RS485 bus, and adopt single-point grounding for cable shielding layers to avoid ground loop noise. Separate all signal cables from high-power AC cables to prevent signal interference. The main module is directly plugged into the control backplane to complete internal bus connection without extra wiring. Install the protective cover after wiring to maintain IP20 protection performance.

•
