ABB PCD232A 3BHE022293R0101 Processor Module

• Brand
  ABB
• Model
  PCD232A
• Product Name
  PEC80-CIO Controller/Processor Module
• Country of Origin
  Switzerland
• HS Code
  85371092
• Dimensions
  147 mm*80 mm*120 mm
• Weight
  0.247 kg (Approximately 0.54 lbs)
• Operating Temperature
  0°C to +55°C (32°F to 131°F)
• Storage Temperature
  -40°C to +70°C (-40°F to 158°F)
• Part Number
  3BHE022293R0101
• Warranty
  12 month
• Product Status
  New and original

ABB PCD232A 3BHE022293R0101 Technical Specifications

Input Specifications: Low-voltage DC internal power system loop supply, typically operating at industrial 24 VDC control power or powered directly via the AC 800PEC backplane bus architecture.

Output / Interface Specifications: Provides high-speed configurable analog and digital feedback outputs, fiber optic connectivity, or internal system bus protocols designed to communicate synchronously with the central processing unit of the AC 800PEC system.

ABB PCD232A 3BHE022293R0101 Product Advantages

Ultra-Fast Processing Speeds: Designed specifically for high-power electronic control applications, matching the rapid cycle times required by UNITROL excitation loops to stabilize generators instantly.

Flexible Configuration Options: The PEC80-CIO architecture allows the module to be custom-tailored to different I/O and processing setups, adapting to varying industrial control requirements.

Superior Noise Immunity: Built with high galvanic isolation and optional fiber-optic signal paths, shielding control electronics from the severe electromagnetic interference (EMI) typical of large power stations.

Seamless ABB Ecosystem Integration: Native compatibility with the broader AC 800PEC control suite and Control Builder software minimizes the time required for engineering, commissioning, and system updates.

Industrial Durability: Crafted with high-grade components in Switzerland to ensure continuous, long-term reliability in high-stakes, heavy-duty utility networks.

ABB PCD232A 3BHE022293R0101 Wiring and Connection Method

System Bus Connectivity: Plugs directly into specialized rack backplanes using a multi-pin high-density industrial connector pin-array.

Field/Signal Wiring: Employs front-facing pluggable terminal connectors (tension clamp or micro screw-terminal style) and embedded fiber-optic or fast ethernet ports to handle high-immunity communication lines, preventing high-voltage interference.

•
  ABB PCD232A 3BHE022293R0101
