SS6501T01 Emerson DCS CSLS Assembly

• Brand
  Emerson
• Model
  SS6501T01
• Product Name
  DeltaV Redundant CHARM Smart Logic Solver (CSLS) Assembly
• Country of Origin
  United States
• HS Code
  8537209000
• Dimensions
  132mm(L)×105mm(W)×52mm(H)
• Weight
  3.0kg
• Operating Temperature
  -20℃ TO +100℃
• Storage Temperature
  -50℃ TO +180℃
• Power Supply
  24VDC
• Warranty
  12 MONTH
• Product Status
  New and original

Emerson SS6501T01 Product Specification Document

Input Specifications

1.Power Supply Input: 24VDC (20~28VDC wide voltage)

2.Field I/O Input: Support 96 LS-CHARMs mixed access (AI/AO/DI/DO arbitrary combination)

3.Communication Input: Dual redundant LSN safety network copper port, twisted pair access

4.Diagnostic Input: Module fault detection, channel fault feedback input

Output Specifications

1.Logic Execution Output: Safety interlock action signal output for shutdown & trip protection

2.Communication Output: Redundant bus data interaction with DeltaV SIS controller

3.Diagnostic Output: LED status indication, fault alarm dry contact output

4.Hot-swap bus output: Internal redundant data interaction between dual CSLS units

Main Functions

1.Safety logic calculation: Complete SIS interlock logic, trip condition judgment and safety action output

2.Mixed I/O centralized processing: Collect and compute 96-channel on-site analog & digital signals via CHARM modules

3.Redundant fault tolerance: Single unit abnormal operation will not interrupt overall safety logic operation

4.Online hot swapping: Replace faulty components without system power-off or process halt

5. Real-time fault diagnosis: Module self-check, channel fault locating and remote fault uploading

6.System synchronization: Data synchronization between dual redundant logic units for consistent logic result

7.Safety isolation: Electrical isolation between field signals and core logic unit to avoid interference breakdown

Product Advantages

1.Highest safety level: SIL3 certification satisfies strict safety requirements of high-risk process industries

2.Full redundant design: Eliminate single-point failure risk, greatly improve system operation reliability

3.Compact integrated structure: Integrate dual logic units, power modules and communication ports, save cabinet layout space

4.High engineering flexibility: Support arbitrary mixing of AI/AO/DI/DO channels, reduce I/O card inventory cost

5.Low maintenance downtime: Hot-swappable design shortens overhaul time and production loss

6.Perfect DeltaV compatibility: Native matching DeltaV DCS & SIS platform, seamless system integration

7.Harsh environment adaptability: Wide temperature and anti-corrosion performance adapt outdoor & chemical workshop installation

Application Cases

1.Oil & Gas Industry: Refinery, natural gas pipeline, offshore platform SIS safety interlock & emergency shutdown control

2.Petrochemical Industry: Ethylene, chemical fertilizer, coal chemical plant reactor, furnace safety trip protection

3.Thermal Power Industry: Boiler, turbine unit overspeed, overtemperature safety interlock control

4.Chemical Pharmaceutical Industry: High-pressure reaction workshop flammable medium safety monitoring & shutdown protection

5.Metallurgy Industry: High-temperature smelting furnace safety interlock and abnormal condition protection

6.Energy Storage Industry: Chemical energy storage battery fire prevention safety interlock system

Core Characteristics

1. Operating Temperature: -40℃ ~ +70℃, adapt to G3 corrosive industrial environment

2. Protection Grade: IP30 metal sealed housing, cabinet DIN rail installation

3. Safety Certification: IEC61508 SIL3, ATEX Zone2, Class I Div2 explosion-proof certification

4. Scan Cycle: 50ms deterministic logic execution, load-independent stable operation

5. Redundant Structure: Dual CSLS+dual power supply full 1oo2D redundancy, zero switching downtime

6. EMC Performance: Meet IEC61000 industrial anti-interference standard

7. MTBF: Exceed 250,000 hours long-term stable service life

•
