GE IS230JPDGH1B Power Distribution Module

• Brand
  General Electric (GE)
• Model
  IS230JPDGH1B
• Product Name
  Power Distribution Module / Power Distribution Board
• Country of Origin
  United States (USA)
• HS Code
  8538900000
• Dimensions
  17.8 cm High x 12.7 cm Wide
• Weight
  0.6 kg to 0.75 kg
• Operating Temperature
  -22°F to +149°F
• Storage Temperature
  -40°F to +185°F
• Power Supply
  24VDC
• Warranty
  12 month
• Product Status
  New and original

GE IS230JPDGH1B Technical Specifications

Input & Output Parameters

Input Voltage Channels: Dual-redundant 28 V DC input terminals (accepting a functional tolerance range of 24 V DC to 32 V DC) derived from the system's primary bulk power supplies.

Maximum Rated Input Current: Supports up to a total aggregated input current of 15 A to 20 A (depending on specific branch utilization).

Power Output Branches: Multiple distributed plug-in connectors (typically mate-n-lok or Euro-style plug headers) designed to supply steady 28 V DC power to adjacent control hardware.

Circuit Protection: Each output distribution path is equipped with dedicated, fast-acting fuses or electronic circuit limiters to isolate faults immediately.

Diagnostic Feedback Signals: Integrated logic outputs that send diagnostic health status, fuse integrity tracking, and voltage presence signals back to the main controller network.

GE IS230JPDGH1B Wiring & Installation Methods

Cabinet Mounting: Securely mount the IS230JPDGH1B onto the designated cabinet sub-panel backing or standardized internal framing using the integrated mounting hardware or mounting standoffs. Ensure proper vertical alignment to promote passive thermal convection cooling.

Primary Input Power Wiring: Connect the heavy-gauge dual DC supply cables coming from the main power source to the primary input screw terminals or terminal blocks. Maintain strict polarity adherence (+24/28 V DC and Common/Return).

Branch Output Connection: Route the individual power distribution cables from the JPDG output plug-in headers directly to the target I/O packs or terminal boards. Use shielded twisted-pair cabling where electromagnetic interference (EMI) is a concern.

Grounding Requirements: Establish a low-impedance ground connection by securing the module's grounding lug or chassis ground plate to the main cabinet structural earth ground wire. This is mandatory to ensure proper noise filtering and surge protection functionality.

GE IS230JPDGH1B Product Advantages & Key Features

High-Reliability Redundancy: Features isolated dual-diode auctioning circuitry on the input stages, allowing the module to seamlessly switch between redundant primary power feeds without a microsecond of system downtime.

Granular Fault Isolation: By splitting power into distinct branches protected by individual fuses, a catastrophic fault on a field instrument is contained locally, preventing a total control system blackout.

Industrial Conformal Coating: The printed circuit board is treated with a high-grade protective conformal coating, ensuring resistance to moisture, airborne particulate matter, and mild chemical corrosive agents typical of power plant environments.

Real-Time LED Diagnostics: Equipped with front-facing status LEDs that give technicians instantaneous visual confirmation of input power presence, active output branch power, and blown-fuse alerts.

•
