MP8200 KONGSBERG DCS Marine Operation Station Computer

• Brand
  KONGSBERG
• Model
  MP8200
• Product Name
  MP8200 Marine Operation Station Computer
• Place of Origin
  Norway
• HS Code
  84715000
• Dimensions
  400 mm × 340 mm × 100 mm
• Weight
  7.02 kg
• Operating Temperature
  -15 °C to +55 °C
• Storage Temperature
  -25 °C to +70 °C
• Power Supply
  100–240 V AC, 50/60 Hz
• Warranty
  12 month
• Product Status
  New and original

Backed by abundant in-stock inventory and nearly 20 years of industry experience, our company stands as a leading player in the industrial control sector.We offer an extensive range of industrial control products covering numerous models. Should you have any other requirements, please feel free to contact us, and we will respond to you promptly.

Our main brand:

1.ABB's module cards, touch screens, controllers, etc., such as PP846 touch screen, IGCT starting with 5SHY, PM starting controller, AI, DO starting input/output module, SP starting Bailey module, etc

2.GE's module card CPUs, such as VMIC starter, IS200, IS215, IS400, IS420 series, etc,

3.Emerson's card components and EPRO probes, Westinghouse 1C series, Honeywell CC series, Schneider 140 series, Envision full series, Bentley 3500 series, Rexroth motors and drives, and Foxboro small modules.

Hardware Interfaces

Input

6 × USB 2.0

RS232 serial port

Audio line-in / mic input

Ethernet ports (data reception)

Output

VGA / DisplayPort video output

USB ports

RS232 serial port

Redundant Ethernet ports (command transmission)

Audio line-out

System Process I/O (via remote I/O modules)

Input Signals

Digital Input (DI): valve position feedback, limit switches, alarm contacts

Analog Input (AI): 4–20mA, RTD for pressure, temperature, level

Pulse / frequency input: speed, flow signals

Serial data input: NMEA data from GPS, gyro, echo sounder

Output Signals

Digital Output (DO): solenoid valves, indicator lights, relays

Analog Output (AO): 4–20mA for control valves

Serial data output: forwarded navigation data

Network commands to remote I/O units

1. Pre-commissioning Check

Inspect mechanical mounting and vibration dampers.

Check power supply wiring and protective earth connection.

Verify all rear connectors: Ethernet A/B, RS232, video, USB and audio ports.

Confirm power voltage matches unit rating (115/230 VAC).

Check for visible hardware damage.

2. Power-on Hardware Test

Connect monitor, keyboard, mouse and power cable.

Switch on power and check boot sequence, fan status and front indicators.

Enter operating system without hardware error alarms.

Check recognition of network adapters, serial ports and graphic card.

Set and synchronize system date and time.

3. Redundant Network Configuration

Assign static IP addresses for Network A and Network B per system drawing.

Ping process stations and RMP remote I/O modules to confirm communication.

Perform network switchover test by disconnecting one network cable.

Eliminate IP address conflicts within K-Chief system.

4. RS232 Serial Port Commissioning

Configure baud rate, data bits, parity, stop bits and flow control matching external sensors.

Connect navigation equipment: gyro, GPS, echo sounder, wind sensor.

Monitor serial data stream to confirm valid NMEA input.

Verify data forwarding function if required.

5. K-Chief Software Commissioning

Start K-Chief operator station runtime software.

Load correct vessel project configuration.

Confirm valid software license without license alarms.

Check online status of all process stations and RMP remote I/O units.

6. Signal and Function Verification

Monitor AI/DI values from RMP modules and compare with field instruments.

Send manual control commands to test DO/AO outputs to field equipment.

Simulate faults to verify alarm pop-up, audio alert and alarm acknowledge function.

Test trend logging and event log storage & query.

Check screen navigation and printer output (if fitted).

7. Peripheral Test

Multi-display output test (multi-screen configuration)

USB devices: USB flash drive, printer, touch screen

Audio alarm function test

Touch screen calibration (touch console version)

8. Stability Test

Continuous running test for minimum 2–4 hours.

Monitor CPU load, operating temperature and network packet loss.

Execute warm reboot and cold reboot to verify automatic software recovery.

Confirm no communication dropout after power cycling.

9. Common Troubleshooting Points

Boot failure: Check power supply, flash disk and memory

Network disconnection: Check cables, IP settings and network hardware

Missing serial data: Verify wiring polarity and communication parameters

Failed connection to RMP I/O: Check bus topology and downloaded project configuration

Software crash: Check project integrity, license status and disk free space
