Description
-
BrandWoodward
-
Model9907-1183
-
Product Name2301A Speed & Load Sharing Governor Controller
-
Country of OriginUSA
-
HS Code8537209000
-
Dimensions356 × 279 × 102 mm
-
Weight1.3 kg
-
Operating Temperature-25°C to +65°C
-
Storage Temperature-45°C to +85°C
-
Power Supply24 vdc
-
Warranty12 month
-
Product StatusNew and original
Woodward 9907-1183 Introduction & Technical Specifications
Product Advantages
1. High control accuracy with steady speed precision of ±0.1%.
2. Supports isochronous and droop mode for automatic parallel load sharing.
3. Built-in overvoltage, undervoltage, short-circuit and signal loss protection.
4. Fast response to sudden load changes with adaptive PID control.
5. Equipped with standard Modbus communication for remote monitoring and parameter adjustment.
6. Vibration-resistant fully enclosed structure, adaptable to harsh industrial environments.
7. Complete self-diagnosis function for fast fault troubleshooting.
8. Plug-and-play compatibility with Woodward standard sensors and actuators.
Woodward 9907-1183 Wiring Diagram Description
This controller adopts terminal block wiring with clear functional classification, the core wiring rules are as follows:
1. Power Wiring: Connect positive power to terminal 0 and negative power to terminal 1, with external fuse protection.
2. Speed Signal Wiring: Connect MPU speed sensor to terminal 2 and 3 via shielded twisted cable, single-end grounding at terminal 22.
3. Actuator Wiring: Connect actuator positive to terminal 20 and negative to terminal 21, shield wire to public grounding terminal.
4. Mode Switch Wiring: External switch controls switching between droop load sharing and isochronous parallel mode.
5. Trim Potentiometer Wiring: 10kΩ potentiometer connected to terminal 23 and 24 for fine speed adjustment.
6. Communication Wiring: Modbus A/B signals connect to terminal 25 and 26 with twisted pair cable.
7. Grounding: Concentrate all shielding and equipment grounding to terminal 22 for anti-interference.
