Description
-
BrandENTERASYS
-
ModelA4H124-24TX
-
Product Name24 Port 10/100 Managed Fast Ethernet Switch Module
-
Dimensions442 mm × 269 mm × 44 mm
-
Weight3.2 kg
-
Place of OriginUnited States
-
HS Code85176200
-
Operating Temperature0 ℃ to +50 ℃
-
Storage Temperature-40 ℃ to +70 ℃
-
Manufacturing part numberP0973JM
-
Warranty12 month
-
Statusnew
A4H124-24TX P0973JM ENTERASYS Function and Features
The A4H124-24TX P0973JM is a 24-port Fast Ethernet managed switch module belonging to the Enterasys A4 series, specially engineered for reliable enterprise edge and access-layer network deployments.
It features 24×10/100BASE-TX RJ45 copper ports, supporting speed and duplex auto-negotiation as well as auto MDI/MDIX crossover to simplify cable connections.
It adopts a non-blocking wire-speed switching architecture, delivering full line-rate packet forwarding on all ports without performance degradation under full load.
It supports IEEE 802.1Q VLAN tagging and Q-in-Q double VLAN, enabling flexible network segmentation and service isolation for multi-tenant or multi-department environments.
It provides robust QoS capabilities compliant with IEEE 802.1p and DiffServ standards, with multiple priority queues to schedule voice, video and data traffic separately and guarantee critical service bandwidth.
It comes with comprehensive security functions, including 802.1X port-based authentication, RADIUS and TACACS+ authentication, ACL access filtering, and DHCP snooping to defend against malicious network attacks.
It supports STP and RSTP spanning tree protocols to eliminate Layer 2 network loops and enhance network redundancy and stability.
It offers diverse management options: CLI console, SNMPv3, and web-based management interface. It is fully compatible with the Enterasys NetSight policy management platform for centralized policy deployment and monitoring.
It supports stackable deployment; up to 8 modules can be stacked together to expand port density and achieve unified configuration and management.
It is equipped with 2 Gigabit SFP uplink ports, which can accept fiber or copper SFP transceivers to establish high-bandwidth uplink connections to core switches or aggregation switches.
This is a hot-swappable module, allowing replacement and maintenance inside the chassis without powering down the whole system, minimizing network downtime during upgrades or troubleshooting.
The MAC address table supports up to 8000 MAC entries to accommodate a large number of connected end devices.
It operates in store-and-forward switching mode to perform complete error checking of each frame before forwarding, reducing bad frame propagation across the network.
It is well suited for connecting office workstations, network printers, IP phones, surveillance cameras and video terminals within enterprise local area networks.
Enterprise office access layer: It connects office workstations, VoIP phones, network printers and wireless access points. It supports VLAN segmentation, port-based identity authentication and priority scheduling for voice traffic to guarantee smooth daily office communications.
Campus network access: Installed in wiring closets of classrooms, dormitories and teaching buildings. It enables user access control and stack deployment to support mass terminal connections for large campus networks.
Retail and hotel network access: Used for front-end workstations, POS terminals, guest room network outlets and surveillance cameras. It helps configure access permissions and logically separate guest Wi-Fi networks from internal business networks.
Auxiliary industrial network access: Interfaces with HMIs, PLCs, field sensors and monitoring devices in factories, water treatment plants, power facilities and metallurgy sites. It delivers stable Fast Ethernet transmission for non-latency-critical industrial control and monitoring data.
Government and public institution edge networks: Satisfies strict requirements for 802.1X authentication, ACL filtering and centralized policy management. It is ideal for terminal access in administrative offices and service halls.
Building integrated low-voltage systems: Aggregates low-bandwidth smart devices including indoor surveillance cameras, access control panels and alarm units. The Gigabit SFP uplink ports provide reliable uplink connectivity toward core switches.
FAQ for Enterasys A4H124-24TX P0973JM Managed Ethernet Switch
Q1: What is Enterasys A4H124-24TX P0973JM?
A: The A4H124-24TX P0973JM is a 24-port managed stackable Ethernet switch from Enterasys A4 series, widely used for industrial and automation network infrastructure. It supports layer 2 switching, QoS, VLAN, link aggregation and multiple management methods.
Q2: How many ports does A4H124-24TX P0973JM have?
A: It comes with 24 x 10/100BASE-TX copper ports, plus uplink SFP expansion slots for fiber connection, supporting flexible network extension for factory control systems and DCS networks.
Q3: What management protocols does Enterasys A4H124-24TX P0973JM support?
A: It supports CLI via SSH/Telnet, web GUI, SNMP v1/v2c/v3, port mirroring, loop detection, 802.1Q VLAN and 802.1p QoS, convenient for remote monitoring and configuration.
Q4: Can A4H124-24TX P0973JM be stacked with other Enterasys A4 switches?
A: Yes, this model supports stacking with other Enterasys A4 series switches to expand port density and build a unified redundant network for industrial control systems.
Q5: What are the common application scenarios for A4H124-24TX P0973JM?
A: It is commonly deployed in DCS, PLC control networks, power plants, oil & gas, manufacturing automation, and industrial rack network cabinets for stable field data transmission.
Q6: Is Enterasys A4H124-24TX P0973JM still in production?
A: This Enterasys A4 series switch is an end-of-life legacy model. We supply tested used and surplus units for replacement and spare parts for existing automation systems.
