IE-9320-26S2C-A Cisco Managed Ethernet Switch new

• Brand
  Cisco
• Model
  IE-9320-26S2C-A
• Product Name
  Catalyst IE9320 Rugged Industrial Managed Ethernet Switch
• Dimensions
  440 mm × 440 mm × 44 mm
• Weight
  5.5 kg
• Place of Origin
  Mexico
• HS Code
  85176200
• Operating Temperature
  ‑40 °C to +70 °C
• Storage Temperature
  ‑40 °C to +85 °C
• Power Supply
  3.2 A
• Warranty
  12 month
• Status
  original

Technical Specifications for Cisco IE-9320-26S2C-A

Port Configuration:

26 × 10/100/1000 SFP fiber interfaces

2 × Gigabit dual-media (RJ45/SFP) combo interfaces

Total Port Quantity: 28 ports

Switching Capacity: 56 Gbps

Forwarding Throughput: 41.6 Mpps

Stacking Feature: Backplane stacking available; mixed-model stacking is supported within the IE9300 product series

Operating Firmware: Cisco IOS-XE

Default Software License: Network Advantage

Power Supply: Field-replaceable unit, dual redundant power input supported, compatible with industrial AC-DC and low-voltage DC power modules

Cooling Mode: Fan-free passive convection cooling

Layer Functions:

Complete Layer-2 switching and full-featured Layer-3 routing functions

Supports VLAN, STP/RSTP/MSTP, EtherChannel and LACP

Industrial Redundancy Protocols: REP, PRP, HSR, MRP ring protocol

Industrial Fieldbus Compatibility: PROFINET, EtherNet/IP (CIP)

Security Capabilities: Secure Boot, firmware image signature validation, Trust Anchor module, ACL, 802.1X, MACsec

Management Interfaces: Console port, USB port, out-of-band management port

Management Approaches: Cisco Catalyst Center, embedded WebUI, CLI, SNMP, RESTCONF/NETCONF APIs

QoS Functions: Sophisticated queue scheduling, traffic classification, marking, rate limiting and traffic shaping

Conformal Coating: PCB with conformal coating to adapt to severe industrial operating conditions

Compliance Certifications: CE, UL, CSA, IEC 61850-3 and relevant IEEE industrial specifications

Alarm Function: External dry-contact alarm relay output

Dying-gasp Notification: Supported to send fault alerts when power supply fails

MTBF: High mean-time-between-failure for industrial-level dependable performance

What is the power consumption of the Cisco IE-9320-26S2C-A?

The Cisco IE-9320-26S2C-A is a rugged industrial non-PoE switch with high-density fiber ports.

1.Typical idle power consumption: 35 W. This thermal reference value is measured under idle condition without any SFP transceiver modules installed and minimal service features activated.

Maximum system power draw: 64 W. This peak value occurs when all ports are fully fitted with SFP optical transceivers and the switch is running under full-traffic working load.

2.Supported hot-swappable power supply modules include PWR-RGD-LOW-DC-H and PWR-RGD-AC-DC-H. Each power module provides 150 W power rating. The device supports dual-redundant power input configuration to improve power-supply reliability for industrial sites.
