YOKOGAWA AFV10D-S41101 Control Unit new

• Brand
  YOKOGAWA
• Model
  AFV10D-S41101
• Product Name
  Duplexed Field Control Unit for CENTUM VP DCS
• Place of Origin
  Japan
• Customs HS Code
  8537101190
• Power Supply
  100‑120 V AC, 50/60 Hz
• Dimensions
  482.6 mm × 207 mm × 265.9 mm
• Weight
  8.0 kg
• Operating Temperature
  0 ℃ ~ +55 ℃
• Storage Temperature
  ‑20 ℃ ~ +70 ℃
• Warranty
  12 month
• Product Status
  new

YOKOGAWA AFV10D-S41101 Function

The AFV10D-S41101 serves as a duplex field control unit designed for the Yokogawa CENTUM VP DCS platform. It supports Vnet/IP and FIO field I/O networks and adopts a 19-inch rack-mounted installation form.

It runs real-time control algorithms such as PID regulation, sequence control and interlock logic, with a maximum processing capacity of 500 control loops per node.

It establishes data communication and signal interaction between the host system and FIO field I/O modules through the Vnet/IP and ESB buses.

Featuring a fully dual-redundant design with dual CPUs, redundant Vnet/IP communication channels and redundant power supplies, it enables seamless automatic failover to keep control operations uninterrupted upon single-side component failure.

It implements LFS1500 field control station capabilities to accomplish field signal acquisition, control output and data processing tasks.

Equipped with integrated hardware self-diagnostics, it keeps monitoring the operating status of CPUs, power units, communication buses and related modules, and generates corresponding fault alarms.

Online hot-swap operation is available for FIO I/O modules without system shutdown.

YOKOGAWA AFV10D-S41101 Features

The AFV10D-S41101 is a duplex field control unit tailored for the Yokogawa CENTUM VP DCS system, featuring 19-inch rack-mount installation.

It implements complete dual-redundant hardware configuration, comprising dual CPUs, redundant Vnet/IP communication channels and redundant power supplies. Bumpless automatic failover is guaranteed to ensure continuous control operation when a single-component fault occurs.

Compatible with Vnet/IP and ESB buses, it enables seamless data interchange between the host system and FIO I/O modules.

Integrated with LFS1500 field control station functionality, it executes PID regulation, sequence control and interlock logic, and supports a maximum of 500 control loops for each node.

Comprehensive onboard hardware self-diagnosis monitors CPU, power supply, communication bus and module conditions in real-time and outputs fault alarms for anomaly notification.

FIO I/O modules support online hot-swap, eliminating the need for system shutdown during module replacement.

Modular construction simplifies field installation, routine maintenance and future system scaling.

Operating temperature spans 0°C to 55°C, well-suited for general-purpose industrial control scenarios.

It meets CE, CSA, FM non-incendive and KC certification requirements.

Built-in battery backup preserves critical control data in the event of power outages.
