2198-P141 Allen-Bradley Kinetix 5700 DC Bus Supply

• Brand
  Allen-Bradley
• Model
  2198-P141
• Product Name
  Kinetix 5700 DC Bus Supply
• Place of Origin
  United States
• Customs HS Code
  85044099
• Power Supply
  678 V DC
• Dimensions
  252 mm height × 85 mm width × 433 mm depth
• Weight
  6.91 kg
• Operating Temperature
  0°C ~ +50°C
• Storage Temperature
  -40°C ~ +70°C
• Warranty
  1 year
• Product Status
  new

How to judge whether Allen‑Bradley 2198-P141 works normally

Visual Inspection and Power Supply Check

Examine the 2198-P141 module for burn marks, cracks, water stains and damaged connectors. Measure the DC bus input voltage and control supply voltage to ensure readings fall within the rated range. Verify terminals are tight and no short-circuit exists before powering up.

Front-panel LED Status Verification

Energize the module and observe front panel LED indicators.

Power LED: Steady ON indicates normal power supply; OFF or flashing points to power abnormality.

Status LED: Solid green for normal operation; blinking green for standby mode; red or flashing red denotes fault or alarm condition.

Fault LED: Keeps off under healthy operating status. When illuminated, check the fault code for troubleshooting.

Communication Test

Check the EtherNet/IP link LED. Establish EtherNet/IP connection between the 2198-P141 and PLC. Confirm the power supply module can be discovered within Studio5000. Ensure stable online connection, tag reading and parameter access without intermittent disconnections.

Parameter Reading and Diagnostic Check

Access the module via Studio5000. Retrieve operational status, DC bus voltage, temperature, current and hardware diagnostic data. Confirm no active faults or pending alarms in the fault queue. Historical alarms can be cleared if necessary.

Static I/O and Safety Circuit Test

Check digital input status (enable signal, safety stop, limit switches) through software. Validate that input state changes align with physical field signals. Verify safety circuit feedback and confirm the STO (Safe Torque Off) status is normal when STO circuit is closed.

No-load Test

Enable the module with the motor disconnected. Send speed or position commands from the controller. Monitor command setpoints and actual feedback values. Confirm the module responds correctly to enable and motion commands without triggering new alarms.

Motor Jog Test (Motor Connected)

Execute low-speed jog commands. Observe smooth motor operation without abnormal noise, vibration or overheating. Compare actual motor current and speed feedback against set values. Monitor for overcurrent, overload or overspeed alarms during operation.

Dynamic Functional Verification

Run basic motion sequences including start, stop, acceleration and deceleration. Confirm the module executes motion commands accurately. Monitor real-time parameters such as speed, torque and DC bus voltage. Ensure no tripping or random faults during continuous operation.

Thermal and Stability Inspection

Maintain continuous operation for a period. Check the surface temperature of the module. Confirm no overtemperature alarm is raised. Watch out for unexpected resets and occasional communication dropouts.

Final Confirmation

The Allen‑Bradley 2198-P141 is deemed in normal working condition if all LED indicators, communication, diagnostic, jog and dynamic motion tests pass, and no active faults exist.

Product family: Kinetix 5700

Catalog number: 2198-P141

AC input voltage: 324–528 VAC, 3-phase (480 VAC nominal)

Control power input: 24 VDC

Continuous DC bus output current: 47 A rms

Peak DC bus output current: 141 A

Continuous output power: 31 kW

Peak output power: 93 kW

Nominal DC bus voltage: 650 VDC

DC bus overvoltage trip threshold: 832 VDC

Internal shunt resistance: 13.5 Ω

Internal shunt resistor power rating: 200 W

Module width: 85 mm

Approximate weight: 6.91 kg

Mounting method: DIN rail mounting

Communication interface: EtherNet/IP, CIP Motion

Relative humidity: 5% to 95%, non-condensing

Short-circuit withstand capability: 200,000 A rms symmetrical

Safety protections: STO (Safe Torque Off), overvoltage, undervoltage, overcurrent and overtemperature protection

Function: Converts three-phase AC input into DC bus voltage to feed Kinetix 5700 servo axis modules, and dissipates motor regenerative energy through the integrated brake resistor.

FAQ for Allen‑Bradley 2198-P141 (Kinetix 5700 DC Bus Supply)

Q1: What is Allen-Bradley 2198-P141?

A1: Allen-Bradley 2198-P141 is the Kinetix 5700 DC bus power supply module manufactured by Rockwell Automation. It converts 3-phase AC input into stable DC bus power to feed multiple Kinetix 5700 servo drives for multi-axis motion control systems.

Q2: What are the key specifications of 2198-P141?

A2: The 2198-P141 accepts 195–528V three-phase AC input, delivers 31kW continuous power and 46.9A continuous DC bus current. It is an 85mm wide cabinet mount module, designed for 480V class servo applications with built-in overvoltage and overcurrent protection.

Q3: Where is Allen-Bradley 2198-P141 applied?

A3: This DC bus supply is widely used in packaging machinery, CNC machine tools, automated material handling, robotic lines and tire manufacturing equipment. It serves as original and replacement spare part for Kinetix 5700 servo system maintenance and retrofitting.

Q4: Can I purchase tested Allen-Bradley 2198-P141 spare parts from your company?

A4: Yes, we supply new original and fully tested surplus Allen-Bradley 2198-P141 modules globally. Every unit undergoes pre-shipment functional testing. We provide 12-month warranty and fast international shipping for industrial automation spare parts.
